BEHRINGER / JT MINI

The JT MINI is an analog polyphonic synthesizer with 3 VCOs, a multi-mode VCF, an arpeggiator and a 16-step motion sequencer.

Portable Analog Polyphonic & Programmable Synthesizer

Inspired by the classic Jupiter synthesizer of the 80s.

Excellent playability with 27 touch-sensitive keys

Pure analog signal path based on authentic VCO, VCF and VCA design

VCO with 4 selectable waveforms: sawtooth, triangle, square and pulse

Sound creation with pulse width modulation

Vintage multimode filter (with resonance) for classic sounds

Switchable 2-pole and 4-pole filter for further sound creation

Extensive play modes including poly, unison and arpeggiator

16-step motion sequencer with 8 memory slots, knob movement recording

LFO with sawtooth, triangle, square and random waves for vibrato, tremolo and wah-wah effects

Voltage controller amp with dedicated ADSR envelope

USB Type C for powering from your smartphone, power bank or computer

Sync I/O for synchronizing with other synthesizers and drum machines

Comprehensive MIDI implementation (including NRPN/CC control of all parameters, bulk load/save)

With the Behringer JT MINI, you can take the power of a legendary synthesizer with you wherever you go! This ultra-compact and ultra-portable synthesizer features a variable waveform VCO, pulse width modulation, a 16-step motion sequencer and fits in a backpack or gig bag!

The Behringer JT MINI is inspired by the classic Jupiter synth, but we've shrunk everything down and added even more features so you can take that sound with you wherever you go. It has a VCO with four selectable waveforms: sawtooth, triangle, square and pulse. You can also choose between polyphonic, unison, arpeggio up, down, up and down and random modes.

The JT MINI's VCF section allows for cutoff and resonance control, and you can also mix in envelope modulation and LFOs controlled by a dedicated ADSR slider. With 27 touch-sensitive keys, the JT MINI offers maximum playability in a small form factor. Combined with an easily programmable 16-step sequencer, this is a versatile, powerful and compact sound shaping machine that will easily fit into your setup. Specifications
Number of Voices
3 Voices

Type
Analog

Oscillator
3 VCO

LFO
1 LFO

VCF
LPF 12/24 dB/octave

Envelope
1 ADSR

Connectivity
Power Switch
Push Button

MIDI In
5-Pin DIN/16 Channel

USB (MIDI)
USB-C

Headphone
3.5 mm TRS, Stereo, 5 mW 32 Ω

Sync
Input/Output

USB
Type
Class Compliant USB-C

Supported OS
Windows 7 and above

Mac OS X 10.10 and above

Volume
Control
Volume: 0-10

Control Section
Switch
Footage Select - 32', 16', 8', 4', 2', 1'

Poly, Uni, Arpeggiator Up, Down, Up & Down, Random

LFO Section
Control
LFO Rate

LFO Delay

Switch (Keyboard)
Waveform Sine, Saw, Square, Random

Oscillator Section
Controls
Pitch Modulation

PWM Modulation

Detune

Switch
Waveform Select

BA6:BA18 Analog Filter Section
Controls
Cutoff

Resonance

LFO Modulation

Envelope Mod

Switch (Keyboard)
Slope 12 dB/Octave, 24 dB/Octave

Sequencer Section
Number of Operations
16 Steps, 10 Patterns

Controls
Tempo

Switch
Memory/Write

Function

Play/Active

Record/Erase

Scale (Keyboard): 1/1, 1/2, 1/4

Metronome On/Off (Keyboard)

Step Trigger (Keyboard)

Freestyle (Keyboard)

Motion Sequence On/Off (Keyboard)

Motion Sequence Smooth (keyboard)

Motion Sequence Clear (keyboard)

Envelope Section
Sliders
A(ttack)

D(ecay)

S(sustain)

R(elease)

Keyboard and Controls
Keyboard
27, Capacitive Touch

Power
Main Connector
USB-C

Indicators
Power LED

Dimensions (H x W x D)
43.2 x 193 x 123.7 mm

Weight
0.38 kg
