JBL / PRX935

JBL/PRX935 is a 15-inch, 6-inch, 2000W high-power 3-way powered speaker.

JBL PRX935 takes professional portable PA performance to a new level with advanced acoustics, comprehensive DSP, unmatched power and durability, and full BLE control through the JBL Pro Connect app. This powered, 3-way, single 15-inch system provides excellent midrange performance and vocal clarity even at maximum volume. This makes it the perfect system for houses of worship, corporate AV providers, or anyone who requires powerful, room-filling sound.

The PRX935's best-in-class DSP package, accessible via the onboard color display or the JBL Pro Connect app, offers 12-band parametric EQ for system tuning, integrated dbx automatic feedback suppression, and more. The JBL Pro Connect app lets you control mixer and DSP functionality on your Android or iOS mobile device, allowing you to manage a wide range of settings and effects. It is possible to control up to 10 JBL Pro Connect compatible systems and speakers.

PRX935 is designed to withstand the harsh environments of travel. 18mm birch cabinet with optimized bracing provides smooth and accurate bass response. The PRX900 series is powered by industry-leading testing and validation protocols.

Features
Transducer:
916G 15 inch ferrite magnet woofer
196H 6 inch ferrite magnet transducer
JBL 2408H-2 1.5 inch polyannula diaphragm compression driver
Updated JBL Image Control waveguide improves dispersion
FEA flare port design reduces air noise and distortion
Low noise and low distortion gain staging design
Light and efficient class D amplifier
Power: 2,000 Watts (Peak)/1,000 Watts (RMS)
Frequency response: 40 Hz - 20 kHz @4π (-10 dB); 46 Hz - 18 kHz @4π (-3 dB)
Directivity: 90° x 50°
Max SPL: 136.1 dB
Crossover frequency: 542Hz; 2100Hz
Color display provides access to comprehensive DSP suite
DriveRack technology enables automatic feedback suppression, system limiter, and speaker delay of 180ms (in 100 microsecond increments) for a precision time alignment system
Optimized presets for subwoofer and full-range speaker pairing
Get complete control of up to 10 JBL Pro Connect-enabled speakers and systems with the JBL Pro Connect app
Brace optimized for 18mm birch cabinets for smooth and accurate low frequency response
I/O:
2 x XLR balanced combo jack
　1 x 3.5mm AUX
2 x XLR-M loop through
1 x XLR-M mixout
2 integrated side handles
Suspension/Mounts: 1 36mm pole socket, 8 M10 suspension points
Quiet fanless operation
Ultra-low system latency: <1ms
Net weight: 36.6 kg (80.6 lbs); Gross weight: 42 kg (92.5 lbs)
Dimensions: 938.5 mm x 446 mm x 434 mm (36.9 in x 17.5 in x 17.1 in) (H x W x D)
Shipping dimensions: 990 mm x 535 mm x 535 mm (38.9 in x 21 in x 21 in) (H x W x D)
