The VAPB-45M uses a popular drainboard-shaped pedal board, and the power supply is built into the bar at the rear. By having a built-in power supply, you can add an effect pedal in the space where the power supply is placed.

■Main features
・Pedal board with built-in power supply
・Medium size and highly versatile that can accommodate about 5 to 8 effect pedals
Feeling of size
・8 DC outlets in total
- 7 of which are isolated DC outlets, 2 of which are variable voltage
・One high capacity 9V/3000mA DC outlet (non-isolated, maximum capacity is total
(depending on current used)
・USB-A/USB-C outlet (USB-C port) convenient for charging and powering peripheral devices
is PD specification)
・Dedicated DC 24V/2A adapter included
・Various DC cables included (including conversion cables, boost cables, and distribution cables)
- Carrying case included

■Main specifications
・DC-DC switching power supply
・Input: DC 24V/2A (=48W, use dedicated AC adapter)
・Output (center minus, maximum 31.5W)
Isolate out: 9V/250mA x 2, 9V/500mA x 3, variable (9V/500mA/12V/
375mA・18V/250mA）×2
Non-isolated out: 9V/3000mA x 1, USB-A (5V/2.5A) x 1, USB-C (max.
18W PD specification, 5V/3A・9V/2A・18V/1A)×1
・External dimensions: 450 (W) x 305 (D) x 70 to 85 (H) mm *Body size not including protrusions
・Body weight: Approx. 1510 g
·accessories:
AC adapter x 1
AC cable x 1
DC cable: 30 cm x 3, 60 cm x 3, 90 cm x 3
Battery snap cable x 1 *Converted to 0006P dry battery terminal
5525 cable x 1 * Converted to special outer diameter 5.5 mm/inner diameter 2.5 mm plug
3.5 cable x 1 *converted to special 3.5 mm TS plug
Boost Y-cable x 1 * Boost using two isolated outputs
Distribution Y-shaped cable x 1 *Distributes one output to two
Cable lock clip x 1
Hex wrench x 2
Gig bag x 1
Velcro: 200 cm x 4.5 cm x 1

【Note】
Depending on the equipment used, the total power supplied from the DC outlet may be approximately 31.5W or more.
If this happens, the protection circuit will activate and the product may not operate properly.
