■Transducer:
915G 15 inch ferrite magnet woofer
JBL 2408H-2 1.5 inch polyannular diaphragm compression driver
■Updated JBL Image Control Waveguide
■Low noise, low distortion gain staging design
■Lightweight and efficient class D amplifier
■Amplifier output: 2,000 W (PEAK), 1,000 W (RMS)
■Frequency response: 48 Hz to 19 kHz @4pi (-10 dB); 60Hz to 16kHz@4pi(-3dB)
■Direction angle: 90° x 50°
■Maximum sound pressure level: 133 dB
■Crossover frequency: 1,920Hz
■Onboard color LCD screen allows access to mixing and DSP
DriveRack technology includes an auto-feedback suppressor, system limiter, and 180 ms speaker delay at 100 microsecond intervals for a precisely timed system
■Optimized presets for pairing full-range speakers and subwoofers
■JBL Pro Connect app allows complete system control of up to 10 speakers and line integration with JBL EON ONE MK2, PRX ONE, and EON700 systems
■G-sensor automatic position detection function optimizes tuning based on main or monitor orientation
■Polypropylene/talcum composite cabinet optimized for rigidity and durability
■Input/output terminal
2x XLR Balanced Combo Jack
1x 3.5mm AUX
　2ⅹ　XLR-M Loop Through
　1ⅹ　XLR-M Mix Out
■Integrated handle (top, side)
■Suspension/Mount: Dual 36mm pole sockets, 6 M10 suspension points
■Ultra-low system latency: <1 ms
■Quiet fanless specification
■Weight: 24.1kg (53.1 lb)
■Packing weight: 28.7 kg (63.3 lb)
■Dimensions: 717mm x 465 mm x 383 mm (28.2 inches x 18.3 inches x 15.08 inches) (height x width x depth)
■Package dimensions: 749 mm x 574 mm x 495 mm (29.5 inches x 22.6 inches x 19.5 inches) (height x width x depth)


The JBL PRX918XLF takes portable PA performance to a new level with advanced acoustic performance, high-performance DSP, unmatched power, durability, and full BLE control via the JBL Pro Connect app. The PRX900 series is recommended for users who need durable, powerful, high-quality sound that fills a space for portable PA or fixed installation acoustics for professional DJs, bands, music venues, etc.

This 18-inch powered subwoofer is designed from the ground up to take advantage of JBL's cutting-edge acoustic innovations. A next-generation driver system with ultra-efficient Class D amplifiers delivers smooth bass with clarity and clarity even at maximum volume.

The PRX918XLF's class-leading DSP package, accessible through the onboard color LCD or the JBL Pro Connect app, includes a 6-band parametric EQ, plus low-pass filter and delay settings for system tuning and delicate tone control.

The JBL Pro Connect app provides complete hardware and DSP control for up to 10 speakers. You can also integrate the PRX900 series models with the JBL EON ONE MK2, PRX ONE, and EON700 series to access app-only features such as speaker snapshots and grouping.

The PRX918XLF is designed to withstand the rigors of touring. Housed in an 18mm birch cabinet with optimized bracing for smooth bass response and increased durability.

■Transducer:
918SG 18 inch ferrite magnet woofer
■FEA flare port design reduces air noise and distortion
■Lightweight and efficient class D amplifier
■Amplifier output: 2,000 W (PEAK), 1,000 W (RMS)
■Frequency response: 30Hz~110Hz @2pi (-10 dB); 35Hz~92Hz@2pi(-3dB)
■Maximum sound pressure level: 134 dB
■Onboard color LCD screen allows access to DSP
DriveRack technology includes an auto-feedback suppressor, system limiter, and 180 ms speaker delay at 100 microsecond intervals for a precisely timed system
■Optimized presets for pairing full-range speakers and subwoofers
■JBL Pro Connect app allows complete system control of up to 10 speakers and line integration with JBL EON ONE MK2, PRX ONE, and EON700 systems
■BLE networking with JBL Pro Connect app
■Ultra-low system latency: <1 ms
■Input/output terminal
2x XLR Balanced Combo Jack
　2ⅹ　XLR-M Pass Through Out
■Integrated handle (top, side)
■Mount: M20
■18mm birch cabinet features optimized bracing for smooth low-frequency response
■Quiet fanless specification
■Weight: 40.7kg (89.7 lbs)
■Packing weight: 47.5 kg (104.7 lb)
■Dimensions: 693 mm x 591 mm x 654 mm (27.3 inches x 23.3 inches x 25.7 inches) (height x width x depth)
■Package dimensions: 732 mm x 703 mm x 766 mm (28.8 inches x 27.7 inches x 30.2 inches) (height x width x depth)
