One Control / Minimal Series AB BOX Black Edition

Due to its simple configuration, this A/B box can switch between two amplifiers, serve as a tuner out, or even be used as an input selector. Due to its simple configuration, the A/B BOX can also be used as an input selector.

■Effects pedals for guitar
■AB Box
■Power supply: DC9V (sold separately, center-minus, EPA-2000 recommended, batteries cannot be built in)
■Black Edition
■Dimensions, weight: 54Wx 48Hx 101mm, approx. 120g
~From the manufacturer's website
The Minimal Series is the smallest and smallest pedal ever made. The Minimal Series pedal can switch one signal into two channels. The pedal comprises a very simple passive circuit that can be used in various ways. For example, it can switch between two amplifiers, as a tuner that can be muted when tuning, or switch the LR stereo output. In addition, the signal can be run from the RED/BLUE output side to the INPUT side. An input selector can instantly switch inputs when using multiple instruments, such as two guitars, basses, or synthesizers on a single amp or mixer channel. The M450 is also an input selector that allows you to instantly switch between inputs when using multiple instruments, such as two guitars, basses, or synthesizers on a single amplifier or mixer channel. To minimize signal impact, the Minimal Series ABBOX uses a mechanical footswitch for a true bypass. The passive circuitry allows operation without a power supply. For a better visibility, a standard center-minus DC 9V adapter (EPA-2000 recommended) is required to display the current output channel with LED indicators.
