■ Line array speaker
■ 1.5"x8
■ 80W
■ 16Ω
■ One piece
■ White

<Specifications>
■ Model Full range, Bass reflex type
■ Reproduction frequency band (-10dB) * 1: 70 Hz-20 kHz (110 Hz-20 kHz: with port cover attached)
■ Nominal directivity angle (-6dB) * 2:
Horizontal: 170 °
Vertical: 40 ° (+ 20 °- 20 °)
■ Practical directional angle (-10dB) * 2:
Horizontal: 180 °
Vertical: 65 ° (+ 32.5 ° -32.5 °)
■ Rated impedance Lo-Z: 16Ω
■ Allowable input
NOISE: 40 W
PGM: 80 W
MAX: 160 W
■ Output sound pressure level (1W / 1m) * 1 * 3: 89 dB SPL (88 dB SPL: with port cover attached)
■ Maximum output level * 4: 111 dB SPL
■ Components: 1.5" cone x8
■ Connector: Euroblock (2-pin) × 2 (Input: +/-)
■ Dustproof and waterproof performance: IP34 (IP35: with port cover attached)
■ White (Munsell approximation: N9)
■ Dimensions (W × H × D) and weight:
(Speaker body only) W54xH480xD104mm, 2.1kg
■ Accessories: mounting bracket x1, bracket base x1, safety wire x1, terminal cover x2, body mounting screw x1, port cover x1
■ One piece
■ Options: WMB-L1W, VCB-L1B, VCSB-L1W, HCB-L1B, ST-L1W
