IK MULTIMEDIA / iRig Micro Amp

Battery-powered compact guitar amplifier with built-in iOS/USB compatible digital interface

○ Main features and specifications of iRig Micro Amp
・Compact guitar amplifier that can be driven by batteries (6 AA batteries)
・High-quality sound 4-inch custom speaker
・15W RMS output (7.5W when using batteries)
・3 analog channels: clean, drive, read
・4 tone controls: gain, low, mid, and high
・Headphone out that is ideal for home practice
・AUX input to which MP3 player etc. can be connected
・4 ohm cabinet out that can be connected to an external cabinet
・Can be connected to iPhone, iPad, computer (Mac/Windows)
・24-bit/96 kHz professional quality sound
・Unlock 10 types of amps and 26 types of stomps from the iOS app AmpliTube CS
(License included)*
・9 types of AmpliTube 4 amps and 10 types of stomps for Mac/Windows can be used*
・Can be used in combination with your favorite apps and software
*For amps and stomps, purchase only what you want from a huge gear of over 280 types.

■ Common
・Speaker: 4 inch full range x 1
・Output: 15W (when using AC adapter)/7.5W (when driven by batteries)
■ Power supply
・Battery-powered (6 AA batteries)
*Driving time (reference): Approximately 15 hours (6 AA alkaline batteries)
・9V-15V output DC power supply (center minus, 1500mA or more)
*Dedicated AC adapter etc. are not included.
■ USB interface
・Resolution: 24-bit A/D, 24-bit D/A
・Sampling rate: 44.1/48/88.2/96 kHz
・Connection terminal: micro-USB
■ Instrument input
・Input jack: Unbalanced TS standard phone, Hi-Z
・Input level: 30 mVpp to 6.9 Vpp
・Input impedance: 1 MΩ
・Frequency characteristics: 20 Hz to 20 kHz ±1.5 dB
■ Stereo headphone output
・Output jack: 1/8 inch TRS (mini stereo) phone
■ External speaker output
・Output jack: Unbalanced TS standard phone
・Output impedance: 4 to 16 Ω
■ Size and weight
・External dimensions: 210 x 125 x 155 mm
・Body weight: 1.26 kg

*Accessories: Lightning to micro-USB cable (60 cm), USB A to micro-USB cable (60 cm), 6 AA batteries, thread adapter for microphone mount stand
(3/8 inch male to 5/8 inch female)

■ Operating environment:
○ Operating environment
・IOS device (when connecting an iOS device)
iPhone X, iPhone 8 Plus, iPhone 8, iPhone SE, iPhone 6s Plus, iPhone
6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPod touch
(6th generation, 5th generation), iPad Pro 10.5-inch, iPad Pro
12.9 inch (2nd generation, 1st generation), iPad Pro 9.7 inch, iPad mini 4, iPad Air
2, iPad mini 3, iPad Air, iPad mini 2, iPad
mini, iPad (5th generation, 4th generation) (iOS 6 or above required)

・Computer
Mac: free USB port on macOS 10.6 or later
Windows: Full support for Windows 10 WASAPI, free USB port (Windows
ASIO4ALL is required for 7 or 8 low latency audio environments. )
