IK MULTIMEDIA / AXE I/O USB接続オーディオインターフェイス

The perfect audio interface for guitar recording.

A premium audio interface made for guitarists!

The AXE I/O is the highest quality 2 IN/5 OUT designed for guitarists.
192kHz compatible USB audio interface & controller. Not only does it bring out the original tone of the guitar to the maximum, but it also has various functions to make the recording of the guitar smoother.

○ Product overview and main features of AXE I/O
The AXE I/O is equipped with many guitar-specific functions even at the input stage alone.
2 mode switches, PURE and JFET, are provided for the main input, and you can switch between a transparent sound without seasoning and a warm sound by adding overtones. In addition, PASSIVE mode for passive pickup and ACTIVE mode for active pickup are available. In ACTIVE mode, unnecessary circuits are bypassed to bring out the original tone of the guitar or pickup. In addition, the patent-pending Z-Tone allows you to adjust the input impedance to match the tone of the connected guitar or pickup. Optimal sound can be obtained that avoids sound thinning and muffled sound due to impedance mismatch.

AXE
I/O is bundled with software and plug-ins worth more than 1,000 euro, so you can enjoy recording, mixing, and mastering right away.
AmpliTube 4 Deluxe is a guitar with over 140 gear models/Bass effects and amp modeling software that includes guitar and bass amps, cabinets, stomp effects, and mics that resemble ultra-realistic analog behaviour. AXE for preset selection and value adjustment
You can also use the knobs on the front panel of the I/O, or connect an external pedal/footswitch to operate the pedals and switches on the AmpliTube. Also, for mix software, T-RackS
10 popular processors, carefully selected from 5, are also bundled. From vintage outboard-modeled compressors and limiters to the popular integrated processor ONE, you can complete world-class mixes and masters. In addition, the free version of Ableton
Live 10
Lite is bundled, so you have all the music production software you need to compose and record audio at once.

■ Features:
[Input/output]
・2 in/5 out (including Hi-Z AMP OUT)
・2 ultra-low noise microphones/standard balanced input
・Z-TONE guitar input with 3 topologies
・Reference headphone out
・2 freely assignable controller inputs
・ MIDI IN/OUT
・ Compatible with Mac/Windows USB 2.0

[Function to bring out the best guitar tone]
・Instrument input that can switch between ACTIVE/PASSIVE pickup and discrete JFET/PURE
・Original Z-TONE technology that can adjust up to the input impedance
・Amplifier output (reamp) that can be connected to an amplifier or stomp while avoiding ground noise
・2 controller inputs that can also connect an expression pedal and a dual foot switch
・PRESET knob that can be freely assigned such as switching AmpliTube presets
・Built-in tuner
・Robust and compact metal body
・Bundled AmpliTube 4 Deluxe

[Studio quality sound]
・High resolution, ultra-low noise Class-A mic preamp
・Best-in-class AD/DA and excellent analog circuit design
・Asynchronous USB audio and ultra-low jitter clock realize high sound quality
・117dB dynamic range
・Dedicated control software
・Supports sampling rate of up to 192 kHz
・Bundles 10 high-quality T-RackS plug-ins and Ableton Live 10 Lite

■ Specifications
○ Operating environment
・Macintosh computer
Mac OS X 10.11 or later, free USB port

・Windows computer
Windows 8 or later, free USB port

■ Highest quality audio interface for everyone
Dynamic range of 117 dB, frequency response of 3 Hz-32 kHz, and continuously adjustable input impedance from 2.2 kΩ to 1 MΩ. These specifications are not found in other audio interfaces. But these are essential to capture your playing accurately and to make your sound pure and transparent.

■ Main features
・Input/output
2 IN/5 OUT (including AMP OUT with ground lift)
2 ultra-low noise mics/standard balanced inputs
Z-TONE Guitar input with 3 topologies
2 balanced + 2 unbalanced line out
Reference headphone out
2 freely assignable controller inputs
MIDI IN/OUT
Compatible with Mac/PC USB 2.0
Function to bring out the best guitar tone
ACTIVE/PASSIVE pickup, discrete JFET/PURE switchable instrument input
Unique Z-TONE Technology that can adjust up to the input impedance
AMP out that can be connected to an amplifier or stomp while avoiding ground noise
2 controller inputs that can also be connected to an expression pedal and a dual foot switch
AmpliTube PRESET knob that can be freely assigned such as preset switching
Built-in tuner
Rugged and compact metal body
Bundled with AmpliTube 4 Deluxe
Studio quality sound
High resolution, ultra low noise class A mic preamp
Best-in-class AD/DA and excellent analog circuit design
Asynchronous USB audio and ultra-low jitter clock realize high sound quality
117 dB dynamic range
Dedicated control software
Supports sampling rates up to 192 kHz
Bundles 10 high-quality T-RackS plug-ins and Ableton Live 10 Lite

Specifications/Operating conditions
size
Dimensions: 23.8cm x 21.1cm x 5.3cm
Weight: 1.3kg
Contents
AXE I/O body
USB A to USB B cable (1.5m)
DC power supply
Operating conditions
macOS 10.11 or later (64-bit) or Windows 8 or later (64-bit)
Free USB port
*Please refer to manufacturer site for detailed product specifications.
