MOOER / GE150 Plus

The Mooer GE150 Plus is a compact, next-generation multi-effects unit that offers exceptional operability. It features a total of 170 effects, including 55 amp models, and can be controlled, managed, and loaded from an editor. It's perfect for any situation, from practice sessions to full-scale live performances.

The Mooer GE150 Plus is a new generation multi-effects pedal featuring a new Walking Star design.
The GE150 Plus features three footswitches for superior operability and sound quality. It features 55 high-quality amp models recreated using intelligent reverse modeling technology. It offers a total of 170 diverse effects, each assigned to nine effect modules, allowing up to nine effects to be used simultaneously. 198 presets can be saved.
You can also load third-party cabinet simulator IRs, allowing you to tailor your own sound using your favorite IRs.
It also supports MNRS amp models sampled from real amps created and shared with Mooer GE Labs or the GS1000. You can also load amp model GNR files (full amp or preamp) and cabinet model GIR files.
The built-in expression pedal allows for real-time control of various parameters, and it also features an 80-second phrase looper, rhythm machine, and tuner, making it ideal for practice and live performances. Connect to a PC via the USB port to edit and manage presets in the editor software, load MNRS amp models and IRs, and output audio to a mobile device via USB-OTG.

■Features
- Mooer GE Series with a new Walking Star design
- 55 realistic amp simulators using intelligent reverse modeling technology to reproduce high-quality amp sounds
- Ability to load cabinet simulations using third-party IRs
- 198 presets
- Built-in expression pedal for volume and parameter control
- 80-second stereo phrase looper
- Drum machine with 40 rhythms and 10 metronomes
- Built-in high-precision tuner
- Spillover tail hold for natural decay of delay and reverb effects when switching presets (between presets with the same effect configuration)
- USB Type-C port supports OTG connection for connecting to editor software for preset editing and data management, as well as audio recording and playback
- AUX IN jack for connecting an external audio source

■Effect Modules
The GE150 Plus includes nine effect modules containing 170 different effects, all of which can be used simultaneously. Each module can be configured to use a single effect type. The effect module LED indicates the ON/OFF status of the effect module within the current preset. The order of the LEDs represents the actual connection order of the modules in the effect chain.

■Tap Tempo
The GE150 Plus allows you to tap the tempo of the delay module and drum machine using the TAP button.

■Onboard Expression Pedal
The GE150 Plus's onboard pedal can be used as an expression pedal to control a single parameter, or as a master volume pedal.
The expression pedal has a toe switch function. This switch allows you to switch between expression mode and volume mode.

■Tuner
Press and hold footswitches A and B simultaneously to activate the tuner. You can also set the tuning mode and reference frequency.

■Drum Machine
The GE150 Plus includes a drum machine that allows you to select drum rhythm patterns or a metronome click.

■Phrase Looper
The GE150 Plus includes a stereo phrase looper with a recording time of up to 80 seconds. To activate, press and hold footswitches B and C simultaneously.

■Spillover
This function provides a tail hold for the delay and reverb effects. Under certain conditions, it can maintain the natural decay of the delay and reverb when switching presets.

Copy the target preset and save it to the destination preset location. In the new preset location, you can adjust the effect module ON/OFF and parameters within the effect chain. Once configured, you can switch between two presets while maintaining the natural tail decay of the delay and reverb.

■OTG Function
The GE150 Plus's USB-C port allows you to connect a smartphone or tablet via OTG (On-The-Go) function for audio recording and playback.

*Please ensure your mobile device supports OTG before using this function. Depending on the interface available on your mobile device, you may need to use an appropriate third-party USB-C OTG adapter cable.

■Editor Software
The GE150 Plus is compatible with dedicated computer editor software. You can edit effect module parameters, import or export preset files, import third-party IR sample files, and back up data.

■Specifications
-Effects
Modules: 9
Effect Models: 170
Preset Storage Slots: 198

-IR
Format: WAV
Sampling Rate: 44.1kHz
Sampling Precision: 24-bit
Sample Points: 512

-Input
Interface Type: 1x1/4"" Unbalanced Mono Input Connector
Input Impedance: 2.2MOhm
Maximum Input Level: 5.75dBu

Audio Analog-to-Digital Converter
Sampling Rate: 44.1kHz
Sampling Precision: 24-bit
Dynamic Range: 5.75dBu
Frequency Response: 20Hz-20kHz

-Output
Interface Type: 2x1/4"" Unbalanced Mono Output Jacks
Output Impedance: 100 Ohm
Maximum Output Level: 11.75 dBu

- Phones Jack
Interface Type: 1 x 1/8"" Unbalanced Stereo Output Connector
Output Impedance: 32 Ohm
Maximum Output Level: 11.75 dBu

- Audio Digital-to-Analog Converter
Dynamic Range: 11.75 dBu
Frequency Response: 20 Hz - 20 kHz
Signal-to-Noise Ratio: 97 dB

- USB Interface: Type-C Connector

- Power Supply: DC9V, 300 mA, Center Negative

- Operating Temperature: 0-60°C
- Dimensions: 255.7 mm x 142.4 mm x 34.4 mm (L x W x H)
- Weight: 926 g
- Accessories: Power Adapter, USB Cable, Quick Guide
