TRICKFISH / Trilobite

Trilobite is a highly flexible dual-channel preamp with routing capabilities suited to modern live environments. The [LF][LF] EQ section features shelving-type Bass and Treble, as well as variable Low Mid and High Mid bandpass EQs, allowing for a wide range of tone adjustments. The [LF][LF] effects loop with parallel/series switching and two direct outputs make it ideal for stage and studio use.

[直輸入品][Direct Import]

■Bass preamp/DI

■Specifications:
・Pre-Amp: Low noise solid state
・Mono/Dual Instrument Inputs: 1/4 phone jack with rotary gain control
・Input Level Indicator: Signal level and Clip LEDs (green/red)

・Channel A EQ: 4 Band with switchable Mid
Bass and Treble
Low-Mid and Hi?Mid -Variable Gain, Band Pass EQ with selectable frequency/bandwidth options

・Channel B EQ: 4 Band
Shelving Bass and Treble
Low-Mid and Hi?Mid -Variable Gain, Band Pass EQ
Master Volume: Rotary Control

・Channel A/B Footswitch
・FX On/Off Footswitch
・Mute Footswitch
・Line In: 1/8” mini jack
・Headphone Out: Stereo 1/8” mini jack
・Tuner Out: ?” Phone jack
・Amp Out: 1/4 phone jack
・EFX Loop: Parallel with side-chain dry blend
・Insert Loop: Series
・Direct Out: 600 Ohm Balanced XLR, Pre/Post, and Ground Lift
・AUX Out: 600 Ohm Balanced XLR, Post EQ
・Power Requirements: 12V DC (250mA minimum)
・Chassis: Aluminum
・Removable Rubber Feet: Adhesive backed
・Size:(H x W x D cm) 3.93 front / 5.20 back x 21.59 x 15.33
・Weight: 0.83 kg
