QSC / KC12-BK

QSC/KC12-BK is a 3-way, 3000W loudspeaker system.

■Active 3-way column speaker system
■Black

DJ / Mobile performer / Musician / Band / Equipment rental / For various events

Inheriting the tradition of the K series, the KC12 is a 3-way 3000W speaker system. It has the beautiful design of a column speaker while achieving acoustic performance that exceeds conventional designs. Simple and quick to install, the KC12 is ideal for solo entertainers, musicians and bands, mobile performers and DJs, video production, and fixed installation sound systems.

The highly portable KC12 system consists of a bass-reflex subwoofer with a 12-inch driver that supports up to 40Hz. The innovative design of the mid/high enclosure combines a 1-inch compression driver with QSC's proprietary LEAF? (Length-Equalized Acoustic Flare) waveguide, and two low-distortion, high-excursion 4-inch midrange drivers. This 3-way design provides excellent 145° horizontal and 35° vertical coverage for clear, natural sound at all output levels.

The system can be configured with or without column poles and is ideal for installation directly on the floor or stage.

■Main features
●3-way speaker system equipped with a 12-inch (305mm) driver, two low-distortion high-excursion 4-inch (102mm) midrange drivers, and a 1-inch (25.4mm) compression driver and unique QSC LEAF waveguide.
●Achieves maximum peak SPL of 132 dB without distortion
●Equipped with an energy-efficient Class D amplifier, providing a total peak output of 3000 W
●Equipped with a power correction function that keeps power consumption extremely low
●Innovative QSC LEAF (Length-Equalized Acoustic Flare) waveguide provides uniform, clear coverage and superior reach of 145° horizontally x 35° vertically
●Two combo XLR/phone inputs (Mic/Line/Hi-Z and Mic/Line/+48 V) with independently assignable factory presets for each input
Multi-function digital display allows operation and selection of parametric EQ, subwoofer levels, presets and scenes, Bluetooth settings, delay (200 ms), and reverb functions
●Bluetooth audio uses True Wireless Stereo (TWS), realizing low-latency pairing between the music source and the left and right speakers.
●Can be installed with or without the pole attached, making it ideal for installation on the floor or stage.

■KC12 specifications
Configuration: Active 3-way column speaker system
transducer
LF: 305 mm (12 inch) cone
MF: 102 mm (4 inch) cone x 2
HF: 25.4 mm (1 inch) compression driver
Frequency characteristics
?6 dB: 45 Hz to 18.5 kHz
?10 dB: 40 Hz to 20 kHz
Directional characteristics: horizontal 145° x vertical 35°
Max SPL: 132 dB (peak) @ 1 m
Amplifier: Class D, 3000 W (KC12S: 2000 W, KC12T: 1000 W)
Cooling: Low noise variable speed fan
control
Rotary encoder x 1
Push button x 2
Rotary level potentiometer x 3
AC power switch x 1
indicator
Monochrome LCD display (45 x 25.4 mm)
Limiter LED x 1 (red)
Power LED x 2 (blue, front and back of subwoofer)
Standby LED x 1 (yellow)
Input A
Input signal/clip LED (signal: green / clip: red)
Microphone/line LED
Hi-Z
input B
Input signal/clip LED (signal: green / clip: red)
Microphone/line LED
+48V
input C
Input signal/clip LED (signal: green / clip: red)
Bluetooth
connector
Lockable XLR/F TRS phone combo input x 2 (Hi-Z / +48 V compatible)
XLR male x 2 (loop-through output/post-DSP mix output)
TRS stereo input (3.5 mm) x 1
USB-C x 1 (5V 3A output, for mobile charging/firmware update)
Locking IEC power connector x 1
Power: 100-240 VAC, 50/60Hz
Power consumption: 1.8~3.7A
system components
KC12T: 145° dual 4-inch column speaker
KC-SP32: 32 inch column system pole
KC12S: 3000W active 12-inch subwoofer
Housing material: Shockproof ABS, 12 mm birch plywood, powder coated aluminum
grill
KC12T: Powder coat steel (21 gauge)
KC12S: Powder coat steel (18 gauge)
system height
High installation: 2270 mm (when using KC-SP32)
Low installation: 1463 mm (when KC-SP32 is not used)
Dimensions (height x width x depth)
　KC12T: 890 × 141 × 158 mm
　KC-SP32: 881 × 74 × 46 mm
　KC12S: 655 × 357 × 455 mm
weight
　High installation: 27.3 kg
　KC12T: 4.0 kg
　KC-SP32: 1.3 kg
　KC12S: 22.0 kg
Attached accessories: KC12 TOTE: Tote bag for KC12T and KC-SP32
Optional accessories: KC12 CVR: Cover for KC12S
Certification standards: CE, WEEE, UL, China RoHS, RoHS II, FCC Class B
