ART / Solo MPA

The ART/Solo MPA is a 1-channel multi-voice vacuum tube preamplifier that combines the best features of both vacuum tubes and transistors.

■ 1-Channel Multi-Voice Vacuum Tube Preamplifier

■ Overview

This unit is a 1U rack-sized microphone preamplifier that combines the advantages of both vacuum tubes and transistors. It blends the pure, low-noise/low-distortion sound of solid-state with the warm sound of Class A vacuum tubes. The wide-ranging and highly effective EQ allows you to achieve your desired sound.

With 48V phantom power and adjustable input impedance, it can be used with various types of microphones, including dynamic, condenser, and ribbon microphones. The low-cut control allows you to clearly accentuate vocals, while the tilt EQ can be used to emphasize high frequencies or enhance the warmth of the low frequencies.

It's also ideal for those who want to further upgrade the microphone preamplifier built into their equipment. The robust 1U rack-sized enclosure ensures reliable use in studios and venues for many years to come.


■Main Features

Adjustable impedance to match various microphones (600-80kΩ)

Tilt EQ

Low-cut filter

Adjustable vacuum tube solid-state voicing

Analog VU meter

Meter trim

Backlit switches

Discrete Class A FET microphone preamplifier

Low gain and low noise

Low THD

Wide frequency response

Instrument/DI input

Very high input impedance

Output level selection (+4dBu / -10dBV)

Automatic switching when an instrument is input

1U rackmount size

Detachable power cord

■Specifications

Frequency response: 15 Hz to 50 kHz (+0, -1dB)

Dynamic range: >110 dB (""A"" weighted)

CMRR: >90 dB

THD: <0.005% (typical)

EIN: -129 dBu (XLR, “A” weighted)

Maximum Input Level: +19 dBu (XLR)

Maximum Instrument Input: +17 dBu

Input Impedance:

600?80 kΩ (XLR), >800 kΩ (Instrument)

Maximum Output Level: +27 dBu (XLR)

Output Impedance: <47 Ω (XLR)

Maximum Gain: 75 dB

Meter Calibration: 0 VU = +4 dBu output (+4 dBu mode)

0 VU = -10 dBV output (-10 dBV mode)

Low-Cut Filter: Single pole, 10?200 Hz

Tilt EQ: ±12 dB

Power Supply: 100V

Dimensions (HWD): 44 × 483 × 152 mm

Weight: 2.5 kg
