JOYO / Zombie

JOYO /Zombie II is a high-gain type amp head reminiscent of the famous Mesa Boogie machine.

Preamp circuit: Operational amplifier + 1 x 12AX7/ECC83
Power amp: CLASS D
Amp power: 20W
Channel mode: CLEAN / OD
Input: AC 110-240V 50/60Hz
OUTPUT：DC18V/2.0A
Dimensions: 163mm*110mm*140mm
Weight：1200g
Power adapter：INPUT AC 100-240V 50/60Hz OUTPUT DC18V/2.0A
Headphone Impedance：Standard 32Ω Minimum16Ω
Speaker Impedance：8 Ω
Controls: Gain, Tone and Volume
Switch: Clean / OD - Power
Fx loop: 6.35mm x 2
Speaker output: 6.35mm
Headphone output: 3.5mm

(This product is sold as an amp head, and does not produce sound by itself. A speaker cabinet for sound output is required separately.)
