IK MULTIMEDIA / iRig Stream iPhone/iPad用オーディオインターフェイス

An audio interface suitable for streaming.

■ Audio interface for iPhone/iPad

■ Specifications/Operating conditions
Common
Quantization: 24-bit A/D, D/A conversion
Sample rate: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Power: USB bus power, DC input (requires iRig PSU 3A (sold separately, DC input charges iOS Lightning device))
Meter: LED x 3
Device connection: mini-DIN
Line input
Connector: RCA x 2 (unbalanced) Left/Right
Input rated level: -10dBV
Input impedance: 16.5 kΩ
Frequency characteristics: 20 Hz to 20 kHz
Headset/headphone output
Connector: 1/8" TRRS jack (compliant with CTIA standard)
Supply voltage: 2.5 V or more
Microphone input gain: Adjustable with "MIC" wheel
Frequency characteristics: 20 Hz to 20 kHz
Headphone level: Adjustable with "PHONES" wheel
Headphone output power: 100 mW @ 50 Ω
accessories:
Lightning to mini-DIN cable (60 cm), USB C-Type to mini-DIN cable (60 cm), USB A-Type to mini-DIN cable (60 cm)
External dimensions: 105.5 x 44.5 x 24 mm
Body weight: 65 g
iOS device
iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPad Pro (10.5 inch), iPad Pro (12.9 inch, 2nd generation), iPad Pro (9.7 inch), iPad Pro (12.9 inch, 1st generation) iPad mini 4, iPad Air 2, iPad mini 3, iPad Air, iPad mini 2, iPad mini, iPad (6th generation), iPad (5th generation), iPad (4th generation), iPod touch (6th generation), iPod touch (5th generation), iOS 6 or later

Mac
Mac OS X 10.6 or later, free USB port

Windows
Full support for Windows 10 WASAPI (ASIO4ALL driver required for Windows 7 and 8), free USB port

Android device
A model that runs Android 5 or later and has a USB audio function (requires a Micro-USB-OTG mini-DIN cable (sold separately))

*Please refer to the manufacturer site Compatibility column for details on the operating environment.
