ART / VoiceChannel

Variations

This channel strip features a discrete Class A vacuum tube microphone preamplifier that delivers a wide range of excellent sounds, along with a compressor, de-esser, gate, expander, and semi-paratomical EQ. It boasts a rich array of inputs and outputs, including preamp outputs and insert inputs, and is further enhanced with a high-quality 16-bit/24-bit 44.1kHz-192kHz compatible AD converter, various digital outputs, and even a USB output, making it a truly multi-functional model.

■Main Features

* Discrete Class A vacuum tube preamplifier

* Variable input impedance (150Ω to 3000Ω)

* Selectable vacuum tube plate voltage

* Low-cut filter

* Compressor, expander, de-esser, gate

* Band semi-parametric EQ

* VU meter & LED meter

* Combo input on the front panel

* Insertion for external effects processing immediately before the AD converter

* Preamp output and insert input for input after the preamp

* High-quality AD converter supporting 16-bit/24-bit 44.1kHz-192kHz

* Digital output: ADAT / AES / EBU / S/PDIF / TOSLink

* Word clock input/output

* USB output for direct output to PC *
* Sample rates are 32, 44.1, 48kHz, and 16-bit. Uses the standard USB 1.1 driver. Supported OS: Windows 98 SE or later, Mac OS 9.1, Mac OS X or later.
