Neunaber Audio Effects / Elements Seraphim Shimmer

Elements Seraphim Shimmer is an evolution of Wet Reverb, which produces a variety of reverberations with simple controls, and also provides a shimmer reverb effect. In addition to the fantastic sound that only the shimmer effect can produce, you can enjoy the high-quality reverberation effect that is unique to Neunaber Audio Effects.

■Guitar Effects
■Reverb
■Features
・Mix control allows 100% wet setting
・Bypass mode can be set
・Analog dry through for low noise and zero latency
・Compact size
・Operates with standard DC9-12V adapter (batteries cannot be used.)
・Made in Orange County, California USA
■Controls
・Mix
The Mix knob controls the balance between the dry signal and the reverb sound.
At minimum counterclockwise, it is 100% dry, and at maximum clockwise, it is 100% reverb (kill dry). At around 3 o'clock, it is 50%:50%.
The Mix knob is designed to allow fine adjustments, so you can easily adjust the strength of the reverb by simply turning the knob.
・Depth
Controls the length of the reverb. It can be used to adjust the width of the space.
・Shim
Adjusts the amount of shimmer in the effect. At minimum counterclockwise, shimmer is disabled.
■Specifications
Input level (Mix<60%): +4 dBV, Instrument Level
Input level (Mix>60%): -10 dBV, Instrument Level
Input impedance: 1 MΩ (mono)
Output impedance: 1 kΩ (mono)
Gain (active/bypass): +/-0.5 dB (dry signal only)
Frequency response: 20 Hz to 20 kHz, +0.1 dB, -0.5 dB (dry signal or bypassed)
Total harmonic distortion: < 0.0015 % typical (dry signal or bypassed, 22 Hz to 22 kHz, 1.0 Vrms, 1 kHz)
S/N: 109 dB dry/bypassed signal (typical, A-weighted), 100 dB Mix @ 50% (typical, A-weighted)
Power terminal: 9-12 V DC, 80 mA　 Plug: center-negative, 5.5 mm OD x 2.1 mm ID
Size: 73 mm W, 117 mm L, 51 mm H
Weight: 200g
