Blackmagic Design / ATEM Television Studio HD

Production switcher for broadcast and audiovisual industries. Equipped with HDMI input, SDI input, multi-view, talkback, DVE, audio mixer, flash media player, etc. You can perform live switching simply by connecting the camera to a game console or computer!

■ Production switcher
■ Total video input: 8
■ Total output: 8
■ Aux output total: 1
■ SDI rate: 270M, 1.5G, 3G
■ Total audio input: XLR x2
■ Total audio output: Not supported (embedded audio only)
■ Time code connection: None
■ SDI video input: 10-bit x4 (SD / HD switchable) 2-channel embedded audio
■ HDMI video input: HDMI (Type A) x4 (10-bit SD / HD switchable). 2-channel embedded audio
■ Reference input: Tri-level sync or black burst
■ Video input resynchronization: all 8 inputs
■ SDI program output: 10-bit x5 (SD / HD switchable)
■ HDMI program output: Not supported
■ SDI audio output: 2 channels embedded in SDI output
■ Computer output: Not supported
■ 280mm X 44mm X 175mm 1.46kg
* The power cable is sold separately.
