SONIC / 579770

The SONIC / TT-201 TURBO SWITCH TC 2 USA is a turbo switch for Telecasters that use the inch standard, such as Fender USA. It transforms your Telecaster into a powerful, powerful instrument without changing its appearance or preserving its original sound. The TURBO SWITCH TC 2 also features full-up pots on the volume and tone controls, bypassing the circuit when the volume is at full volume for improved clarity.

■Turbo Switch for Telecasters
■Inch Size
(Threaded Pot Diameter: 3/8 inch)
■Control Layout: Master Volume / Master Tone and Turbo ON/OFF
■Controls
~The tone knob is a push-pull turbo ON/OFF switch~
~Turbo OFF: Tone control not pulled up~

This is the same as a regular Telecaster, allowing you to produce the sound of the front, mix, and rear single-coil pickups.
~Turbo ON: Tone control pulled up~
・The front and rear single-coil pickups are connected in series, producing a powerful sound regardless of the pickup selector position.
・Unlike the normal center position, which mixes them in parallel, the sound is reliably thicker and more powerful. If the front and rear pickups are reverse polarity, noise cancellation is also achieved.
・The tone control can be used regardless of whether the turbo is on or off.
■ Features a full-up potentiometer that bypasses the circuit when fully turned up, improving sound clarity.
■ Passive type that requires no batteries.

~From the manufacturer's website~
The ""Turbo Switch TC"" is an original circuit that transforms a standard Telecaster into a guitar with powerful, powerful tone when you need it most, without changing its appearance or compromising its original sound. It connects the Telecaster's two single-coil pickups in series to extract power. It's not a preamp, so no batteries are required. When installed, the tone knob becomes a push-pull switch. As shown in the diagram to the right, when pressed down, it's in the normal position, and when pulled up, it's turbo-on. Of course, when turned, it functions as a tone control. The pickup selector switch is made by CRL, a highly durable American manufacturer, and the tone circuit uses oil capacitors for a smooth, responsive tone. Furthermore, the Turbo Switch TC2 features full-up potentiometers for the volume and tone controls, bypassing the circuit when fully turned up, improving sound clarity.

*Images are for illustrative purposes only.
*When replacing guitar/bass parts, there may be minor differences in specifications, so we do not guarantee or confirm installation. Please be aware that part replacement requires modification.
