TC HELICON / VoiceTone D1

The VoiceTone D1 is an easy-to-use vocal effect processor that adds depth to vocals with realistic doubling emulation.

■Compact Vocal Effects Pedal: Doubling/Detune

From the dawn of modern recording technology to the present day, the unison doubling effect has been widely used by numerous highly successful artists. The VoiceTone D1 recreates this effect with TC-Helicon's sophisticated vocal algorithm. The VoiceTone D1 features eight meticulously tuned styles; simply select a style and press the footswitch to instantly obtain sounds previously only available in recording studios.

■Key Features

? Eight practical styles of unison and octave doubling:

Tight, Loose, Group, Detune, Thick, Octave Up, Octave Down, Shout

? Mix knob with center notch; the center setting provides the recommended doubling level.

? High-quality doubling algorithm reminiscent of overdubbing effects.

? USB port for computer connection. You can obtain or view firmware updates, news, and usage tips from the VoiceSupport application.

* Phantom power compatible (always on, measured value: approx. 21V)

■ Versatile doubling effects

The VoiceTone D1 generates a thick doubling effect by applying a subtle pitch shift to the lead voice. Enjoy single and multi-voice doubling, including octave shift and classic detune options, as well as powerful group shouts.

Input

■ Microphone Input Impedance: Balanced: 2.68 kOhms

■ Microphone Input Level @ 0dBFS: -42 dBu to +1 dBu

■ EIN @ Maximum Microphone Gain Rg=150 Ohms: -126 dBu

■ Microphone Input S/N Ratio: >104 dB

Output

■ Output Impedance, Balanced/Unbalanced: 200 Ohms/100 Ohms

■ Full-Scale Output: +1 dBu

■ Dynamic Range: >104 dB, 20 Hz to 20 kHz

■ Frequency Response +0/-0.3 dB: 20 ??Hz to 20 kHz

Power Supply

■ Power Supply (Included): 12V, 0.4A

■ Power Consumption: 5.6W

Other

■ Dimensions: 140 x 90 x 60 mm

■ Weight: 420 g

*Please connect the output to the XLR microphone input terminal using an XLR female-to-XLR male microphone cable. Connecting to a TS/TRS phone line input terminal may result in noise, insufficient volume, or noticeable noise when increasing the gain, preventing normal use.

*When connecting to an XLR input terminal of a mixer, etc., please use with the phantom power from the mixer turned OFF, as this may cause malfunction.

*The phantom power supplied by the effects unit is approximately +21V (measured value), so condenser microphones requiring +48V cannot be used.

*[Notice regarding TC HELICON product software ""VoiceSupport 2""]

Currently, ""VoiceSupport 2"" can be downloaded from the manufacturer's website, but there have been reports of issues where the device is not properly recognized (e.g., ""Device in use"" is displayed) in the latest environments such as Windows 11 after 2025.

We apologize, but at this time, you will have to wait for the manufacturer to release an improved version. We will promptly notify you through news and other channels when the latest version is released.
