AMERICAN AUDIO / VERSAPORT

An audio interface that can easily perform digital sound sources such as cassette tapes and records. In addition to the analog 4 in 4 out of RCA terminal, it also has a headphone terminal and a microphone terminal for monitoring. Compatible with USB bus power and can be used in combination with various recording software just by preparing the main unit and cable.

Easy to convert analog to digital!

Versaport is an audio interface that facilitates analog-to-digital conversion. You can connect to a computer via USB and easily record using your favorite software.

Specifications
・ 16bit / 48kHz AD / DA converter
・ USB 1.1 compliant
・ Microphone level adjustment knob
・ Monitor level adjustment knob
・ Line / phono selector
・ Headphone output
・ Input x1ch (phone terminal) for dynamic microphone
・ Input / output 4IN / 4OUT (output is fixed at stereo 2ch)
・ RCA analog connection
・ USB bus power compatible, no power adapter required
・ Dimensions and weight: 13L × 12W × 4Hcm, 0.15kg

Compatible software
・ Windows: MME, MS DirectSound, Steinberg ASIO & Audition
・ Macintosh: Garage Band, Audio Hijack Pro (OSX) & Sound Manager (OS9)

System requirements
・ Windows
OS: Microsoft Windows 98 / 98se / ME / 2000 / XP
Computer: Windows computer with USB terminal
CPU / Clock: pentinum II processor 233 MHz or more (win98 / SE / ME)
Pentinum II processor 400MHz or more (win2000)
Memory (RAM): 64MB or more
Hard Disk: 120MB or more
Display: 800x600 or more / 65,536colors (16bit High Color) or more

・ Macintosh
OS: MacOS9.2 or higher, or Mac OSX.
Computer: Apple Macintosh series with USB terminal
CPU / Clock: PowerPC G3 / 300MHz or higher
Memory (RAM): 96MB or more (Application memory 32MB or more)
Hard Disk: 120MB or more
Display / Colors: 800x600 or more

* Windows 7 is supported by downloading / installing the dedicated driver from the manufacturer site.
