Erica Synths / MIDI DISPATCH

Erica Synths' MIDI DISPATCH is a high-quality, latency-free 8-channel MIDI thru/splitter housed in a sturdy aluminum case.

The MIDI DISPATCH is the successor to Erica Synths' first desktop unit, the MIDI THRU BOX.
As the command center of your studio environment, it offers significantly improved ease of use and expandability.

This unit is a splitter that distributes one MIDI input to eight channels with ultra-low latency, and also features advanced MIDI filtering.

It can also be connected directly to a laptop via USB-C, allowing you to control up to eight pieces of equipment simultaneously from a MIDI keyboard or sequencer.

Each output can be configured independently, making it flexible for both studio and live performance environments.

Technical Specifications
Connectors: 1 x DIN5 MIDI input, 8 x DIN5 MIDI outputs, USB-C input/output
Latency: 0 seconds in MIDI Thru mode, 0.5 ms with MIDI filtering
Power: 9-12V DC (minimum 100mA), center positive or USB-C
Dimensions: 222 x 35 x 48 mm
Weight: 0.5 kg
Included Items: MIDI Dispatcher unit, USB-A to USB-C cable
