TECH21 / RK5 FLY RIG V3 Richie Kotzen Signature Model

TonePrint Loader with 14 legendary TC guitar effects and MASH footswitches

Main features
◆Design your own multi-model TonePrint pedal
◆With 2 slots on 7 boards, you can save and recall 14 TonePrints from the TC TonePrint pedal series.
◆Slot A and slot B can be selected by holding down the foot switch in A/B mode.
◆MASH footswitch for real-time expression control
◆1-inch IPS LCD screen displays effect type and parameter information
◆Full stereo input/output
◆Connectable to PCs and mobile devices via Bluetooth and USB
◆By connecting to the TonePrint app, you can access expanded parameters and create your own custom TonePrint.
◆Easily set artist settings with Toneprint
◆3 universal control knobs for quick and fine adjustments
◆Hall of Fame II, Flashback II, Sub n Up, Corona Chorus, Viscous Vibe, Quintessence, Pipeline are pre-installed.
◆Analog dry-through preserves the integrity of the original signal.
◆True bypass or buffered bypass (optional)

specification
◆Bypass mode: True Bypass (Buffered Bypass optional)
◆Input terminal: 2 x 1/4"" TS, unbalanced, mono
◆Input impedance: 1 MΩ
◆Output terminal: 2 x 1/4"" TS, unbalanced, mono
◆Power: Standard 5.5 / 2.1 mm 9 VDC, >= 250 mA, center negative
◆Control: Board select knob, 3 parameter knobs (assignable) MASH footswitch (assignable), 2-way toggle switch, BT connect button
◆Latency: 0.8 - 2.3 ms (with look-ahead dynamics feature enabled)
◆USB port: USB C connector for firmware updates and TonePrints

◆Bluetooth
Version: Version 5.1 low energy
Operating frequency: 2400 to 2483.5 GHz
Channel Number: 40
Max power output:4dBm
Working distance :Up to 10 m measured in open space (wall and structures may affect range of device)
