SOURCE AUDIO / SA164 Neuro Hub

128 Preset External memory unit that transforms into One Series!!

Neuro Hub can store up to 128 One Series parameter settings, control options, effect ON/OFF settings, etc. in its internal flash memory. Saved presets can be recalled using a MIDI controller, and in addition to recalling presets, you can also control parameters in real time.

Control with the Hot Hand 3 or expression pedal connected to Neuro Hub is not only compatible with One Series pedals, but also with older models Soundblox 2, Soundblox, and Soundblox Pro, allowing you to control up to 5 devices at the same time.

■SPEC
Power:
40mA 9V DC (up to 80mA when using motion sensor)
2.1mm center pin minus
Expression Pedal Input:1/4″ TRS cable
Tip＝Hot
Resistance value 10k to 50kΩ
Multi Function Inputs:TRRS 3.5mm plug
Weight:170g
Dimensions: W 97 x H 36 x D 53 mm
Accessories: DC9V adapter
Daisy chain cable (1m) x 3
USB cable (A-Mini B type)
