D'Angelico / Excel EXL-1 Dark Iced Tea Burst

The Excel EXL-1 Dark Iced Tea Burst is an original single cutaway archtop hollow body model that is 17 inches (431.8 mm) wide and 3 inches (76.2 mm) thick.

The original pickguard, characteristic of D'Angelico, is five-ply black and designed to resemble a part of an f-hole.
The body, headstock and neck are decorated with binding, and the design, combined with the mother-of-pearl split block position markers, gives a chic and gorgeous impression.
The body top is spruce, and the sides and back are flame maple.
The neck is a three-piece structure (maple/walnut/maple) with walnut sandwiched between maple, which is resistant to warping and twisting, and it has an ebony fingerboard and a 25.5-inch (648 mm) scale.
It also has a dual-action truss rod that is adjusted on the headstock side.
The distinctive headstock design continues the D'Angelico tradition.
The truss rod cover is made of aluminum, and its striking design is inspired by the skyscrapers of New York City, where Art Deco architecture (such as the Empire State Building) was popular around 1930.
The pickup is equipped with a USA Seymour Duncan 59 humbucker.
There is one volume and one tone control.
The hardware is all gold, and it features reliable Grover Imperial machine heads and an ebony bridge and stair step tailpiece.
The color is dark iced tea burst with a gloss finish.
Hard case is included.

Headstock Shape: Standard
Logo Inlay: Mother of Pearl D'Angelico New York Logo
Series Inlay (Front): Mother of Pearl Excel Shield Logo
Serial Number (Back): Model Name, Serial Number
Binding: 3-ply
Finish: Gloss
Headpin: Cupola
Tuners: Grover 150 Imperial
Strings: 12-52
Truss Rod Cover: Aluminum Skyscraper
Nut Width: 1 11/16" (43mm)
Nut Material: Graphtech NuBone XL


Material: Ebony
Binding: 3-ply
Fretwire: Jescar 47/104 Nickel Silver
Scale Length: 25.5" (648mm)
Radius: 12" (304.8mm)
Top Inlay: Mother of Pearl Split Block
Fret Number: 22


Material: 3 piece (Maple/Walnut/Maple)
Finish: Gloss
Profile: C-Shape
Joint Type: Set Neck
Truss Rod: Dual Action


Body Shape: Single Cutaway
Body Style: Hollowbody
Body Depth: 3" (76.2mm)
Body Width: 17" (431.8mm)
Color: Dark Iced Tea Burst
Finish: Gloss
Top Material: Laminated Spruce
Back Material: Laminated Flame Maple
Side Material: Laminated Flame Maple
Binding: 7-ply
Bridge: Floating Ebony Wood
Tailpiece: D'Angelico Stairstep
Pickguard: Solid Black Scalini (5-ply)
Knobs: 2 Mini Hexagon
Strap Buttons: Gold, Locking


Overview: 1 Full Humbucker
Controls: 1 volume / 1 tone
Pickup (Neck): USA Seymour Duncan 59 Humbucker (Neck) (Gold Cover)
Additional Pickup Information: Alnico V
Pots: 500k
Output Jack: Standard Mono


Hardware Color: Gold


Case: Deluxe Hardshell
