ALEXANDER PEDALS / SUGARCUBE

Stereo chorus/vibrato/rotary effect pedal based on the sweet chorus sound of the 1980s with innovative features added to design a new sound. By adding vibrato, rotary speaker, and pitch shift to the traditional chorus sound, we have created a new and unique effect pedal with four effect modes.

Four effect modes in a single unit

0CHO: A mode that creates traditional chorus to vibrato. Additional chorus voices can be added to add depth to the effect.
DIM: A “non-shaking” chorus mode that combines two opposing delay circuits. With the addition of a feedback control, even a flanger-like chorus sound can be created.
0ROT: This mode emulates a rotary speaker. The mix control is set to maximum for the most realistic effect.
ICE: This mode adds a pitch-shifted voice to the chorus and combines it with the chorus. The pitch can be selected from 1 octave down, unison detuned (slightly off pitch from unison), a full 5 degrees or 1 octave up.

Guitar Effects
Digital time modulator
Sugarcube
Controls: RATE / STEREO, DEPTH / RAMP RATE, MIX / VOLUME, TWEAK / CLOCK, SELECT
Switches: RAMP / MOM x 1, BYPASS / PRESET x 1
Bypass: Buffered analog bypass
Dry signal: 24-bit DSP
DSP: 24-bit + 32-bit controller
Sampling frequency: 36kHz -> 8kHz
Input/output terminals: Input, Output, Multi, DC In
Power supply: 9VDC (optional power supply recommended: Music Works / DC0913B)
Current consumption: 100mA
Input Impedance: 1M ohms
Output impedance: 560 ohms
Dimensions: H57 x L122 x W74mm
Weight: Approx. 296g
