JBL / AWC62BK

AWC62-BK is a ceiling-mounted speaker that uses a 6.5-inch coaxial driver. Compliant with IP-56 and can be used outdoors. Comes with U-shaped metal fittings that have been treated to prevent rust. The high-quality coaxial driver outputs clear and natural sound throughout the area. The color is black.

The smallest model in the series that uses a 6.5-inch low-range coaxial driver.
Equipped with top-class weather resistance such as IP-56 and MIL810, it can be used even in harsh outdoors.
Comes with U-shaped metal fittings that have been treated to prevent rust. Can be installed on flat surfaces as well as corners.
The high-quality coaxial driver outputs clear and natural sound evenly over the entire area.
The coverage angle is 110° x 110°, covering a wide area with one stick.
One cable supports both low and high impedance.


Frequency range (-10dB) 70Hz to 18kHz
Coverage angle (horizontal x vertical) 110° x 110°
Maximum sound pressure level 120dB SPL (peak)
Sensitivity (1W, 1m) 92dB SPL
Nominal impedance 8Ω
Transformer tap 100V 120W, 60W, 30W
70V 120W, 60W, 30W, 15W
Allowable input*1 175W
Driver configuration LF 6.5 inch (165mm)
HF 1 inch (25mm)
Crossover frequency 1.8kHz
Input terminal Screw terminal
Applicable cable φ4.1~9.1mm*2
Enclosure Glass-filled ABS resin, light gray/black (-BK)
Dimensions (W x H x D) 259 x 259 x 258 mm (removed protrusion)
Mass 7.0kg
Accessories U-shaped bracket, U-shaped bracket mounting screws (screws x 2, washers x 2, spring washers x 2), panel cover, cover mounting screws x 4, cable clamp
