Austrian Audio / OC818 black Studio Set

Austrian Audio's OC818 is the world's first multi-pattern & dual output condenser microphone with wireless control options.

Featuring a CKR12 dual ceramic capsule, handmade in Vienna, Austria, multi-polar pattern, high-pass filter/pad, open acoustic technology, 255-level directional design/remote control with the PolarPilot app, and even dual-output post-production with the PolarDesigner plug-in, this microphone combines tradition and modern technology.


■Handmade CKR12 dual ceramic capsule
Designed and handmade in Austria with the same critical dimensions as the legendary CK12 capsule. Resistant to touch noise due to suspension structure

■Multi-pattern
Unidirectional, superunidirectional, omnidirectional, bidirectional, designable presets in the PolarPilot app

■Analog polarity voltage control
Remote control of directivity and various functions via Bluetooth from the PolarPilot app

■3-stage high-pass filter and 2-stage pad
Filter: 40 Hz/80 Hz/160 Hz, Pad: -10 dB/-20 dB

■Dual output
You can output and record the front/back of the diaphragm separately.

■Stereo pair anytime
Since the individual sensitivity differences shipped are adjusted to within 1dB, any two, regardless of whether they are OC818 or OC18, can be used as a stereo pair.

Product specifications
■Color: Black
■Large diaphragm condenser
■Capsule: CKR12 dual ceramic capsule
■Directivity: unidirectional, super unidirectional, omnidirectional, figure directional, custom preset (designed with PolarPilot app)
■3-stage high-pass filter: 40 Hz (2nd harmonic filter), 80 Hz (2nd harmonic filter), 160 Hz (1st harmonic filter and 2nd harmonic filter below 80Hz)
■2-stage pad: -10 dB, -20 dB
■Output terminals: XLR 3 pin and mini XLR 5 pin (for rear diaphragm output and OCR8 Bluetooth dongle sold separately)
■Remote control
Connect the optional OCR8 Bluetooth dongle to the rear mini-XLR 5-pin terminal and use the free PolarPilot app to remotely control directional/highpass/pads.
■Frequency characteristics: 20 Hz - 20 kHz
■Maximum SPL: 158 dB
■Impedance: 275 Ω
■Impedance load: > 1 kΩ
■Sensitivity (omnidirectional): 13mV/Pa
■Noise level: 9 dB SPL (A-weighted)
■Voltage: 48 V (< 4mA, typical value 2.1mA)
■Size: 157 x 63 x 35 mm
■Weight: 360g
■Country of manufacture: Vienna, Austria

・OC818 microphone
・Japanese guide
・Carrying case
・OCS8 Spider Mount
・OCW8 windscreen
・OCH8 microphone clip
・Mini XLR/XLR cable for OCC8 rear diaphragm
