LYNX STUDIO TECHNOLOGY / AURORA(n) 24 - TB3

LYNX STUDIO TECHNOLOGY / AURORA(n) is a next-generation mastering-grade AD/DA converter/audio interface that pursues sound quality and functionality. It comes with a reassuring 3-year Sound House warranty!

■Thunderbolt 3 Audio Interface

This 24-channel model connects to your computer via Thunderbolt 3, allowing up to six devices to be daisy-chained to a single Thunderbolt port.

A wide variety of input/output numbers and connection formats are available.

""Lynx Studio Technology's renowned transparent sound has earned their converters the attention of leading recording facilities and various audio applications around the world. The AURORA(n) takes this to the next level, with even greater precision than ever before.

"" Even within a single rack space, the AURORA(n) features an analog signal path for each channel, designed as an independent, shielded circuit.

This design offers numerous audio advantages, including improved dynamic range and performance while significantly reducing crosstalk and distortion.

Newly designed high-performance sample clock technology, SynchroLock 2 delivers an astounding 300,000:1 jitter reduction, a 5-second lock time, and extremely high accuracy. With one BNC connector for word clock input and output and three outputs, it's ideal as a master clock for small systems.

Despite its compact, single-rack-space design, the AURORA(n)'s modular architecture offers exceptional expandability. Optional LSlot cards allow for a variety of interfaces, including Thunderbolt 3, DANTE, Pro Tools|HD, and USB. Expandable options include adding analog I/O modules in 8-channel increments for up to 32 channels, digital I/O modules, and mic preamp modules.

Other features include a built-in microSD recorder supporting up to 32 channels of direct recording and playback, and two high-end audio-grade headphone outputs with independent volume controls, making this converter ideal for a wide range of applications.

Analog Input Terminals
AURORA(n) 24: DB25 x 3

Analog Output Connectors
AURORA(n) 24: DB25 x 3

Dimensions: 44 x 480 x 228 mm (H x W x D), 19-inch 1U rackmount size
Weight:
AURORA(n) 24: Approximately 3.27 kg
Power Supply: 100V-240VAC/Max 70W

Computer equipped with an Intel Core 2 @ 1.6 kHz or equivalent AMD processor
2GB or more of free RAM
Windows 10 Fall Creators Update (64-bit edition)
macOS 10.12 Sierra, 10.13 High Sierra, 10.14 Mojave
One available Thunderbolt 3 port (Thunderbolt 1/2 compatible, requires an Apple adapter, sold separately)
Thunderbolt 3 cable (Sold separately)

*For details on the operating environment for each connection format, please refer to the distributor's website.
