WARM AUDIO / BUS-COMP Stereo Compressor

Focusing on classic circuitry that has delivered smooth tones for decades, this is a fully analog, 2-channel stereo VCA bus compressor perfected with unique options. Its appeal lies not only in its precise dynamic control but also in the deep tone it adds to the sound it passes through.

■Stereo Bus Compressor

The Warm Audio BUS-COMP is an all-analog, 2-channel stereo VCA compressor based on classic circuitry that has delivered silky smooth tones for decades. Stereo VCA compressors excel at controlling the dynamics of any source, but they have become widely known for their magical touch to stereo mixes.

The BUS-COMP is ideal for stereo mixes, drum mixes, drum overheads, acoustic guitars, keyboards, pianos, orchestral instruments, narration, and a wide variety of other sources. While primarily designed for stereo, the BUS-COMP can be used similarly with individual mono sources. This type of VCA compressor is appealing not only for its easy dynamic control, but also for the added tone and depth it provides to the audio signal even when compression is not applied.

While recreating legendary VCA compressor technology is the concept behind the BUS-COMP, there is also a focus on adding and refining options. One of its key features is the BUS-COMP function, which allows you to insert American-made CineMag transformers into a signal path driven by fully isolated op-amps. With a single press of a front panel switch, these custom-made transformers are inserted into your audio path, enhancing depth, tone, and atmosphere!

■Features and Specifications

? All-analog, 2-channel stereo VCA compressor

? Designed based on legendary VCA compression technology

? CineMag USA transformer and selectable discrete op-amp stage

? External sidechain source selection

? Switchable high-pass filter: 30, 60, 105, 125, 185Hz

? Flexible compatibility with stereo mixes, drum mixes, drum overheads, acoustic guitar, keyboards, piano, orchestral instruments, narration, and virtually any other source

? Can also be used in mono

? THAT 2180 VCA

? Supports XLR and TRS

? Noise: <-90dBu

? Headroom: > +29dBu, 20Hz - 20kHz

? Dynamic Range: > 120dB

? Frequency Response: 18Hz - 22kHz

? THD + Noise, 20Hz - 20kHz, + 20dBu Input: <.05%

* Input Impedance: 10k ohm

* Output Impedance: 50 ohm

*This product is designed for 115V in its country of origin, but can also be used in a 100V environment in Japan.
