MANLEY / MRAG

This MANLEY condenser microphone features a switch on the back of the head basket to select between omnidirectional and cardioid modes. It also features a low-pass filter switch. It's ideal for a variety of applications, including vocals, brass instruments, drum overheads, and string instruments. It also includes a dedicated shock mount and genuine leather capsule protector.

Features
■ Condenser microphone
■ Josephson Audio's handcrafted American-made capsule, based on the vintage Sony C-37A
■ Single-sided large diaphragm
■ 5-micron thick, 1-inch gold-plated large diaphragm
■ Dual polar pattern (omnidirectional and cardioid)
■ Variable vent for continuous variation between omnidirectional and cardioid (not linear)*
■ Low-pass filter switch (-3 dB @ 55 Hz)
■ Tube head amplifier (5670 tube)
■ Hand-wound, nickel-core Manley Iron output transformer
■ Custom-designed dedicated power supply
■ Dedicated shock mount (Manley X-Cradle suspension) included
■ Genuine leather capsule protector included
*Always turn off the power and unplug all cables before adjusting polar pattern.

Specifications
■Vacuum Tube: 5670
■Frequency Response: 10 Hz to 30 kHz, AMP to 60 kHz
■Sensitivity: 7 mV/Pa
■Noise: -108 dBV (A-Weighted)
■Maximum SPL: 150 dB
■THD+N: 0.05% or less, 22 to 22 kHz bandwidth (1 kΩ, 1 kHz -40 dBV output)
■Output Impedance: 200 Ω
■Power Consumption: 15 W
■Operating Voltage: 90 V to 250 V
■Fuse: 2 A slow blow
■Dimensions
■Microphone: 4.5"" x 4.5"" x 9.7"" (approx. 114.3 mm x 114.3 mm x 246.4 mm)
■Power Supply: 5"" x 3.4"" x 8.2"" (approx. 127 mm x 86.36 mm x 208.3 mm)
■Weight
Microphone: 1.5 lbs (approx. 680 g)
Power Supply: 1.5 lbs (approx. 680 g)
