RME / Digiface Dante Audio Interface

This compact audio interface incorporates RME's highly reliable and proven technology into the audio network technology ""Dante."" It also supports MADI, and together with Dante, it achieves 256 channels of input and output. The remote control software TotalMix Remote allows for flexible routing even in large-scale systems. It uses high-bandwidth USB 3.0 and can also be run as a standalone. Comes with a reassuring 3-year Sound House warranty!

The Digiface Dante is RME's first audio interface to support the Dante networking standard, which is increasingly being adopted in PA, installation, studio, and conference systems. RME's driver technology, renowned in the audio interface market, maintains low latency and stability while intuitively handling up to 256 channels of audio data. The built-in headphone output can be used for headphone monitoring or as a stereo line output.

The Ethernet ports that connect to the Dante network are equipped with two primary and two secondary ports, for a total of four ports, providing redundancy and allowing use as a four-port switching hub. It also supports standalone mode, functioning as a simple ""Dante<>MADI converter"" and ""Dante & MADI patchbay."" Pre-configured settings also allow for headphone monitoring of any mix.

RME's MADI transmission technology recognizes the clock within the MADI signal when connecting to MADI devices, eliminating the need for a separate word clock connection.
* The MADI coaxial input/output terminals can be switched to use with the word clock input/output terminals.

Specifications
MADI Input
75 ohm coaxial (BNC), AES10-1991 compliant
High-sensitivity input stage (<0.2 Vpp)
56/64 channel mode, 96 k frames supported
Standard: Up to 64 channels, 24 bits, 48 kHz
S/MUX: 32 channels, 24 bits, 96 kHz
S/MUX4: 16 channels, 24 bits, 192 kHz
Sync Bandwidth: 25 kHz to 54 kHz
MADI Output
75 ohm coaxial (BNC), AES10-1991 compliant
Output Voltage: 400 mVpp
Cable Length: Up to 50 m
56/64 channel mode, 96 k frames supported
Standard: Up to 64 channels, 24 bits, 48 kHz
S/MUX: Up to 32 channels, 24 bits, 96 kHz
S/MUX4: Up to 16 channels 24-bit 192 kHz

General
Power Adapter: USB bus powered or external power supply
Idle Power Consumption: 3 watts
5V Bus Power: 600 mA
Maximum Idle Power Consumption: 6 watts (1.2 A)
Dimensions (WxHxD): 170 x 26 x 84 mm
Weight: 500 g
Operating Temperature: +5°C to +50°C
Relative Humidity: 75% or less, non-condensing
