STAGE EVOLUTION / SM1600DX

Fog machine equipped with a 1600W die-cast aluminum heater system. High density fog can be output while maintaining excellent quietness. Equipped with a large 5-liter tank. A hanging bracket is included, so it can be suspended from the ceiling. A large amount of fog can be output in a short time.

■ Fog machine
■ Heater: 1600W
■ Output: 594.6m3 / min
■ Tank capacity: 5L
■ Controller: LC-5 included
■ Controller input terminal: XLR3PIN
■ Controller cable length: 8m
■ DMX compatible: ○ (2CH mode)
■ Warm-up time: 8 minutes
■ Dimensions: D43.5 × W28.0 × H29.5cm
■ Weight 10.5 kg
■ Power supply: AC100V 50 / 60Hz
* 1 Fog liquid is sold separately. Also, it cannot be output only with fog liquid fragrance.
* 2 Since the fog machine requires warm-up, it cannot output fogs all times.
* 3 Depending on the output amount and environment, the smoke detector may respond.
* 4 Note that if the power is turned on for a long time (1 hour or more), the internal temperature fuse will easily blow due to overheating.
* 5 The fog machine may not be able to output due to clogging of the heater unit. If the heater unit is clogged, it is not covered by the warranty.
* 6 At the time of repair / support at our company, there is basically no alternative machine available. We ask that customers prepare spare equipment. In case of a failure, it will normally be treated as a repair, and replacement of a new product will be handled only at the time of initial failure according to technical support and technical judgment.
