STAGE EVOLUTION / フォグマシン

This fog machine is equipped with a 1600W die-cast aluminum heater system. It can output dense fog while maintaining excellent quietness. It is equipped with a large 5 liter tank. It comes with a hanging bracket, so it can be used by hanging it from the ceiling. It can output a large amount of fog in a short time.

■Fog machine
■Heater: 1450W
■Output: 594.6m3/min
■Tank capacity: 5L
■Controller: LC-5 included
■Controller input terminal: XLR3PIN
■Controller cable length: 8m
■DMX compatible: Yes (2CH mode)
■Warm-up time: 8 minutes
■Dimensions: D43.5×W28.0×H29.5cm
■Weight: 10.5 kg
■Power supply: AC100V 50/60Hz
※1 Fog liquid is sold separately. Also, fog liquid fragrance alone cannot be used for output.
※2 Fog machine requires warm-up, so it cannot be output continuously.
※3 Depending on the output amount and environment, it may react to a smoke detector.
※4 Please note that if the power is turned on for a long time (more than 1 hour), the internal temperature fuse is likely to blow due to overheating.
※5 Fog machine may not be able to output due to clogging of the heater unit. Clogged heater units are not covered by the warranty.
*6 Generally, we do not provide replacement units when providing repairs/support. We ask that you prepare a spare unit yourself. Malfunctions will be treated as normal repairs, and replacements will only be available in the case of initial defects, and will be handled at the discretion of our technical staff in accordance with the support regulations.
