ROLAND / DP603-PWS 電子ピアノ

ROLAND is proud of its supernatural piano modeling sound source and PHA-50 keyboard, which make it a highly expressive electronic piano.

■ Sound source
Piano sound Piano sound: Supernatural piano modeling sound source
Maximum Polyphony Piano: Unlimited (when soloing "Piano" tone button)
Other tones: 384
Tones 307 tones

■ Keyboard
PHA-50 keyboard: Hybrid structure (wood x resin center frame), with escapement, ivory tone/ebony tone (88 keys)

■ Pedal
Damper pedal (continuous detection)
Soft pedal (continuous detection/function switchable)
Sostenuto pedal (function switchable)

■ Speaker system
Speaker 12 cm x 2
Rated output 30W x 2
Sound pressure level when playing the piano: 108 dB (*According to our measurement method)

■ Headphones
Headphones 3D ambience compatible

■ Tuning
Keyboard touch Key touch: 100 levels, fixed
Master tuning 415.3-466.2Hz (0.1Hz unit)
Temperament 10 types (equal temperament, pure tone (major/minor), Pythagoras temperament, Kirnberger Ⅰ, Kirnberger Ⅱ, Kirnberger Ⅲ, mid-tone temperament, Bergmeister, Arabic scale), main note can be specified
Effect ambience, sound brightness
Piano designer Orochi
Key off noise
Hammer noise
Aliquot
All-key string resonance
Damper resonance
Key-off resonance
Cabinet resonance
Sound board type
Damper noise
88 key tuning (stretch tuning)
88 key volume
88 key characters
■ Built-in song: 375 songs
■ Data playback
Reproducible data SMF (format 0, 1)
Audio file (WAV format, 44.1kHz, 16-bit linear, USB memory required)
■ Recorder
Recordable data SMF (format 0, 3 parts, about 70,000 sound memory)
Audio file (WAV format, 44.1kHz, 16-bit linear, USB memory required)
■ Bluetooth
Audio Bluetooth standard Ver 3.0 (supports content protection by SCMS-T method)
MIDI, turning pages Bluetooth standard Ver 4.0
■ Convenient function
Convenient function Metronome (tempo/beat/strong beat/pattern/volume/timbre changeable)
Twin piano (separate mode compatible)
Transpose (semitone unit)
Speaker volume/headphone volume automatic switching
Volume limit
Panel lock
Auto off
■ Other
Display Graphic LCD 132 x 32 dots
Connection terminal DC In terminal Input terminal: Stereo mini type
Output (L/Mono, R) terminal: Standard type
USB Computer terminal: USB B type
USB Memory terminal: USB A type
Phones terminal x2: Stereo mini type, stereo standard type
Power AC adapter
Power consumption 9 W Accessories Instruction manual
"Safety precautions" leaflet
"How to assemble the stand" leaflet
Warranty
Roland user registration card
Music sheet collection "Roland Classic Piano Masterpieces"
Music sheet collection "Piano Arrange Collection"
AC adapter
Power cord
Fall prevention metal fittings
Headphones
Headphone hook
Cord clamp
Dedicated high and low chair, sold separately USB memory (*1)
*1 Please use the USB memory and wireless USB adapter sold by Roland. We cannot guarantee operation if other products are used.
■ Dimensions: (Including stand, lid closed) Width 13998 x Height 783 x Depth 311mm
(Including stand, with lid open) Width 13998 x Height 975 x Depth 377 mm
Weight: 11.4kg
*Including fall prevention metal fittings
