The AT-MX862 is a full-matrix digital mixer with 8 inputs and 8 outputs. It supports both mic and line inputs. It features a select function that allows channel selection from four stereo systems. It also features a key lock function to prevent accidental operation and a rotary volume control for superior external control. The front panel is compactly equipped with a wealth of functions, including volume and gain adjustments, signal LED displays, a mute function, and scene recall.
■Type: Matrix Mixer
■Maximum Gain: 65dB or more (1kHz, 600Ω load)
■Maximum Input Level (1kHz, T.H.D. 1%): MIC: -44dBu or more, LINE: -14dBu or more
■Reference Input Level: -61dBm (Output = +4dBm)
■Input Impedance: MIC: Approx. 7.5kΩ, LINE: Approx. 12kΩ
■Reference Output Level: Balanced: +4dBm (reference value), Unbalanced: -2dBv (balanced output reference value)
■Output Impedance: MIC: Approx. 300Ω, LINE: Approx. 450Ω
■Noise Level: -125dBv or less
■Balanced Output T.H.D.: 0.1% or less
■Frequency Response (MIC Input - Line Output, TRIM Maximum): 20-20,000Hz
■Phantom Power: +48V DC
■Power Supply: 100V AC 25W
■Operating temperature range: 0-40°C
■Dimensions: 48.2(W) x 8.8(H) x 364.5(D)cm
■Weight: 5.6kg
■Accessories: Power cord, software installation CD-ROM
- Supports mic/line inputs and features a select function that allows channel selection from four stereo channels
- Output can be set to mono or stereo, allowing use as a stereo mixer
