CELESTION / T5832

Variations

The Celestion TF1230S is an ideal replacement woofer for the Mackie SRM450 Ver. 1, 2, and 3. It boasts 300W RMS and 600W continuous power handling, with 96dB sensitivity. This easy-to-install, rugged 12-inch ferrite pro audio speaker features a Kevlar cone, a sturdy steel chassis, and an optimized magnetic circuit for powerful power delivery.

■Diameter: 12""
■Impedance: 8Ω
■Power Rating: 600W
■Frequency Range: 50-4000Hz
■Sensitivity (1W/1m): 96dB
■Magnet: Ferrite
■Dimensions: 317.5mm x 317.5mm x 137mm
■Weight: 4.3kg
■Other:
■Voice Coil: 3""
■Magnet Weight: 1.7kg
■Chassis: Pressed Steel
■Voice Coil: Edgewound Copper Clad Aluminum
■Former: Polyimide
■Cone: Kevlar-Loaded Paper
■Surround: Cloth-Sealed
■Suspension: Single
■Baffle Diameter: 283mm
■Threaded Hole Size: 13 x 6.6mm
■Number of Threaded Holes: 4
■Mounting PCD: 299mm range

- 12-inch low/mid-range woofer unit with ferrite magnet
- 600W power handling capacity, 96dB sensitivity
- 3"" heat-resistant copper-clad aluminum voice coil wound on reliable polyimide
- Sealed surround, damping, and Kevlar cone for reduced distortion
- Double-roll surround for superior sound projection
- Rigid chassis for maximum power delivery
- Optimized for the Mackie/SRM450V3

■TF Series
The TF Series uses a ferrite magnet in a pressed steel chassis. Available in sizes from 4"" to 15"", it is recommended for a wide variety of PA speakers. Thanks to its uncompromising design, engineering, manufacturing, and quality control, it is favored by many professional users. It is compatible with a variety of cabinets, including 2-way, 3-way, monitor, and bass amps, and is ideal for small to medium-sized applications.

■LF Pressed Chassis / Ferrite
This series uses a ferrite magnet in a pressed steel chassis. The lineup ranges from 4"" to 15"", and is recommended for a wide variety of PA speakers. Thanks to their uncompromising design, engineering, production, and quality control, they are beloved by many professional users. They are compatible with a variety of cabinets, including 2-way, 3-way, monitor, and bass amps, and are ideal for small to medium-sized applications.

■CELESTION
Founded in 1924 as a brand specializing in the manufacture of speakers for guitar amps. They have established an unshakable reputation while supporting the legendary performances of guitarists such as Jimi Hendrix and Slash. Classic speakers such as the VINTAGE30 and CELESTION BLUE are installed in guitar amps from renowned manufacturers such as MARSHALL, VOX, and BOGNER. They also manufacture various drivers and PA woofers, which are used in concerts around the world.

*Woofer units can usually be replaced with models of similar size, impedance, and power handling. However, when actually paired with a speaker, there may be slight mismatches in the screw holes or baffle size, requiring modification. Please note that we do not check or guarantee the installation of woofer units.
