PANASONIC / WT-HS130

The WT-HS130 trumpet speaker is a high-impedance speaker with three output modes, and features clear sound that's perfect for public relations and announcements.

■ Trumpet speaker
■ Input impedance: 30 W: 330 Ω, 20 W: 500 Ω, 15 W: 670 Ω
■ Rated input: 30 W
■ Output sound pressure level (※1): 110 dB (1 m/1 W)
(※1) The output sound pressure level is a value specified by JIS and differs from the value for the ""second signal"" voice alarm.
■Frequency Response: 200 Hz to 6 kHz (-20 dB)
■Operating Temperature Range: -20°C to +55°C
■Water and Dust Resistance: Complies with IP65 and JIS C5504
■Dimensions: (Diameter) 510 mm x (Depth) 504 mm (Total Height Including Mounting Bracket) 510 mm
■Weight: Approximately 4.4 kg
■Finish:

Horn Mouth: Aluminum, Light Gray (Approx. Munsell N7.0)

Reflector: ASA Resin, Light Gray (Approx. Munsell N7.0)

Cover: ABS Resin, Gray (Approx. Munsell N4.0)

Mounting Bracket: SPHC Steel, Hot-Dip Galvanized

External Screws: Stainless Steel
