AMT ELECTRONICS / B-2

A 2-channel amp simulator/preamp pedal that reproduces the sound of the Bogner Extasy preamp. By connecting to the FX RETURN of a guitar amp, you can create sounds that are not affected by the characteristics of the amp. In addition, the newly equipped "OUT DRIVE" terminal can be used by connecting to the input of an amplifier like a general distortion pedal.

[直輸入品][Direct Import]

■ 2ch guitar amp simulator / preamp / distortion pedal
The second in a series of pedal-type preamps that completely reproduce the sound of famous guitar amp preamps with compact analog circuitry. With the new "OUT DRIVE" terminal, it is now possible to connect to the input of a guitar amp not only as a preamp but also as a distortion effect. In addition, a clean channel common to all models is newly implemented. I show a wider sound variation and flexibility.

■Bogner Extasy type
The B-2 is an emulation of the Bogner Extasy, which is indispensable in talking about metal and hard rock since the 1990s. It boasts deep and heavy distortion and a wide sound range that supports 7-string guitars and down-tuning.

■ "Let's carry your own sound in your pocket"
AMT ELECTRONICS' LEGEND AMP series is a preamp series that responds to the desire to produce the sound you like with any amp. Any guitar amp with an FX RETURN jack can be connected, and the preamp section of the guitar amp can be bypassed, making it possible to create sounds that are not affected by the sound color of the guitar amp. .

■ 2ch specification
The output from the "OUT PREAMP" and "OUT CAB.SIM." terminals operates as a clean and lead 2ch preamplifier. When the effect is off, the EQ is bypassed and switched to the 1 volume clean channel. The sound character of the clean channel is common to all models, and it is a FENDER amp style sound. Also, the "CL.BOOST" switch allows you to switch the tone balance of the clean channel. At the output from the "OUT DRIVE" jack, the clean channel is disabled and bypassed.

■ Connection
Three types of output terminals can be used simultaneously according to the application.

・OUT DRIVE:
When connecting the preamp section of a guitar amp in series with this unit, connect this jack to the input of the guitar amp. At this output, the instrument's clean channel is disabled and bypassed.

・OUT PREAMP:
You can get the output from the preamp. Connect to FX RETURN of guitar amp or power amp.

・OUT CAB SIM.:
Adds cabinet emulation to the output from the preamp and outputs the sound. You can connect directly to mixers, interfaces, etc.
When this terminal is not connected, the power consumption is automatically reduced from 6mA to 4mA, and it is also excellent in power saving.

・IN:
Connect your guitar.

■ Specifications
・3 outputs that can be used simultaneously (CAB SIM OUT, PREAMP OUT, DRIVE OUT1)
- Clean level and clean boost controls (CAB SIM OUT and PREAMP OUT only)
・Power supply: AC adapter/9-12v DC center minus or battery
·Low power consumption
・Size: 110 x 62 x 58mm
