MXR / MC-403 POWER SYSTEM

MXR / MC-403 POWER SYSTEM

  • MXR / MC-403 POWER SYSTEM画像1
  • MXR / MC-403 POWER SYSTEM画像2
  • MXR / MC-403 POWER SYSTEM画像3
  • MXR / MC-403 POWER SYSTEM画像4
  • MXR / MC-403 POWER SYSTEM画像5
  • メーカーサイトManufacturer Site
■ Power supply
■ It is a power supply system that is isolated (insulated) and current limited by all output transformers and is overloaded protected.

■ Specifications
・ 9VAC output 800mA 2.5 x 5.5mm x 2
・ 9VDC output 80mA 2.1 x 5.5mm x 8 pieces
・ Variable voltage output x 2
Selectable from 6.5-10.5VDC and 10.5-15.0VDC, 200mA 2.1 x 5.5mm
・ 18VDC output 125mA 2.1 x 5.5mm x 4 pcs
・ AC100V code output terminal x 1

■ Accessories
・ Rack mount panel
・ Mounting bracket for pedal board
·cable
2.1x5.5mm S-L Length 1 "x4
2.1x5.5mm S-L Length 2 "x8
2.1x5.5mm S-L Length 3 "x4
2.5x5.5mm S-L Length 4 "Red x2 (AC9V output only)
2.1x5.5mm S-S Length 2 "x1
2.1x5.5mm S-S Length 3 "x1

■ Dimensions: 343 (W) x 102 (D) x 44 (H) mm

■ Weight: Approximately 2.6kg

関連商品

レビューを投稿するWrite a Review

  • この商品のレビューを書くWrite a Review

MXR (エムエックスアール)
MC-403 POWER SYSTEM

Item ID:156423

26,800 yen(excl. tax)

(29,480 yen incl. tax)
