ALKALITE / SMART STRIP MASTER

When using multiple master units as master units, DMX addresses are automatically assigned, so there is no need to make complicated settings. The slave unit can perform the same control operation as the connected master unit. The perfect equipment to add color to shelf shelves or accent product displays!

■ LED bar
■ Master unit
■ LED: 3in1 (red blue green) LED (0.2W × 6)
■ DMX compatible (3 or 5DMXch)
■ Beam angle: 120 degrees
■ LED life: 50,000 hours
■ 8-pin dedicated connector connection
■ Number of links: up to 30 master units only, up to 36 master and slave units combined
■ Operable temperature: -10 to 50 ° C
■ Power consumption: 1.6W
Power supply: DC24V (power adapter sold separately)
■ Dimensions: 14.5W × 2.2H × 1.2Dcm
■ This product comes with one ALKALITE / TP-15-MB.

* 1 AR-CBL010, AR-PS120, CCS-36 and DMX controller are required to turn on the LED.
* 2 The DMX address cannot be changed because it is automatically assigned to each master unit from 1ch. Be careful when using multiple DMX devices.
