MOOER / Liquid

The Mooer Liquid is a pocket-sized phaser pedal that combines five phaser modes and three waveforms to create a wide range of phasing effects.

Choose from five phaser types with a simple knob, from gentle vintage phasing to extreme modulation. You can also adjust the phaser mix by changing the knob position. You can also select three waveforms (round, triangle, and square) with a toggle switch.

The SPEED control adjusts the phaser modulation speed. The COLOR control operates differently depending on the phaser mode.

・Mode 1: Depth control
・Mode 2: Q control
・Mode 3: Feedback control
・Mode 4: Q + Feedback control
・Mode 5: Q + Feedback control

From classic phaser sounds to completely new modulations, Liquid is all you need.

●Features
- Includes 5 types of phaser effects
- Choose from Round, Triangular, and Square waveforms
- Speed, Color, and Mode/Mix controls
- Full metal housing
- Ultra-compact design
- True bypass
- Powered by a standard DC9V adapter

●Controls
- MODE/MIX: Select from 5 phaser types and adjust the wet/dry mix of the phaser by moving the knob within each mode area.
- SPEED: Adjusts the modulation speed.
- COLOR: Controls the overall tone of the phaser.
- Shape: Choose from 3 waveforms: Round, Triangular, and Square.

Specifications: Input: 1/4"" mono audio jack (impedance: 470kΩ)
Output: 1/4"" mono audio jack (impedance: 100Ω)
Power: Regulated center-negative DC 9V adapter (batteries not supported)
Current Draw: 130mA
Dimensions: 93.5mm (D) x 42mm (W) x 52mm (H)
Weight: 140g
