DPA / 6061OCUF90

This lavalier microphone delivers unparalleled sound quality despite its diameter of just 3mm.

- The subminiature microphone capsule is approximately 60% the size of the previous model's capsule (φ5mm).

- CORE technology delivers distortion-free, transparent sound quality across the entire frequency range. From whispers to screams, you'll enjoy the natural, clear DPA sound.

- A single grid provides a 4dB boost from 8kHz to 20kHz.

◆ High durability for even the toughest environments

- The microphone body is nano-coated with a water-repellent coating, and the amplifier is hermetically sealed, achieving high durability and complying with IP58 standards*.

Dustproof Class 5: Harmful dust particles cannot enter the microphone.

Waterproof Class 8: Water cannot penetrate the microphone even when submerged in water for a long time.
*Testing was conducted by DPA Microphones at Force Technology, a third-party testing organization based in Denmark.

- The diaphragm is double gold-plated.

- The microphone capsule and grid are made of metal with a PVD coating that is impact-resistant and highly abrasion-resistant.
- Like the previous model, it uses a φ1.6mm microphone cable. It's made of durable Kevlar material, and the connection point with the connector also comes with a cable relief for added strength.

◆Excellent maintenance
- The grid can be removed for cleaning. It features a click mechanism that allows you to confirm that it's properly attached when it's returned to the microphone capsule.
- The microphone itself can also be washed with water.

◆Wireless compatible
- Using a separately sold wireless adapter, it can also be used with various companies' wireless microphones. Direct-mount adapters for major wireless systems such as Shure and Sennheiser are also available.

Specifications
Type: Lavalier Microphone
Polar Pattern: Omnidirectional
Cartridge: Prepolarized Condenser
Frequency Range (±2dB): 40Hz–20kHz, 4dB soft boost @ 8–20kHz
Sensitivity (±3dB @ 1kHz): -44dB re. 1V/Pa
Equivalent Noise Level (A-weighted): 26dB(A) re. 20μPa
Total Harmonic Distortion (THD): Less than 1% (128dB SPL peak)
Dynamic Range: 102dB
Maximum Sound Pressure Level: 144dB
Output Impedance: MicroDot: 30–40Ω, DAD6001-BC: 100Ω
Cable Length: Up to 300m (using DAD6001-BC)
Power Supply: Wireless: 5V-10V, Wired (DAD6001-BC): Phantom DC 48V ±4dB
Colors: Black, Beige, Brown, White
Weight: 8g (including cable and MicroDot terminal)
Microphone Head Dimensions: H3.4 x W14.4mm (with grid attached)
Capsule Diameter: 3mm
Cable Length: 1.8m
