TEENAGE ENGINEERING / TX-6 black

The TX-6 field mixer is an ultra-portable mixer and audio interface.

The
TX-6 is a 6-channel stereo mixer or 12-channel mono with built-in equalizer, filters, compressors, aux sends, cues, and digital effects. This ultra-portable mixer can also be used as a multifunctional USB audio interface.

Many features in a small chassis
The first portable pro mixer that can be used as a 32bit/48kHz multifunction audio interface. Use the built-in synthesizer or sequencer, or control it with an external MIDI device.

With an instrument tuner and built-in sound generators (4 waveforms, 4 drum machine sounds), the TX-6 has fun features to help you create music on the go.

The smallest conceivable size
TX-6 is encased in durable aluminum and features custom-made encoders and faders. Thanks to its rechargeable battery, the TX-6 can be taken anywhere from home to the studio.

Features]
6 stereo inputs
3 stereo outputs

[Input/output terminals]
32bit/48kHz USB interface
3.5mm mini jack to 6.3mm jack
Headset mic input
AUX output
Connects to iPhoneR via Lightning cable
Each input is stereo or mono
Headset mic support - USB audio/midi
Built-in effects
Bluetooth Low Energy - OLED display
Rechargeable battery

Input/output terminals】
32bit/48kHz USB interface
3.5mm mini jack to 6.3mm jack
Headset mic input
AUX output
Connected to iPhoneR via Lightning cable
Each input stereo or mono

Dimensions and Weight】
90 mm (102 mm with adapter) x 62 mm x 23 mm
160 g / 5.6 oz

[Characteristics]
Audio Input
Impedance 10kOhm
Analog Gain 0-42 dB
Max Level 8 dBu, 2 Vrms
TLV320ADC3140 burr-brown
SNR?102 dBA
Audio Output (Main and Aux)
Max Level 8 dBu, 2 Vrms
Cirrus Logic masterhifi CS43131
SNR > 120 dBA
Audio Outputs (CUE)
Max Level 2 dBu, 1 Vrms
Cirrus Logic CS47L35
SNR > 110 dBA

[Maintenance Notes]
Operating ambient temperature: 0-50°C (32-122°F)
Storage ambient temperature: 0-30°C (32-86°F)
Dust on the faders should be removed with pressurized air.
To keep the battery healthy, the unit should be charged at least every 6 months.
