MADRIX / AURA 2

MADRIX is a standalone controller with 2 x 512 channel inputs and outputs that allows you to freely record and play back lighting effects.

■ Power Supply: DC 5V to 24V (A: 2-pin terminal block, B: USB 5V)
■ Power Consumption: Typical 2.5W (Max. 500mA)
■ Network Protocol: Art-Net (I-IV, ArtSync compatible), Streaming ACN (sACN / ANSI E1.31)
■ RDM Support: Returns status and sensor data as an RDM Responder
■ DMX Output: Up to 2 universes (512 channels x 2 via Ethernet)
■ DMX Output: Up to 2 universes (512 channels x 2 via Ethernet)
■ Remote Input: 8 universes (via Ethernet) or HTTP control
■ Memory Card: SD / SDHC / SDXC (up to 64GB tested)
■ Ethernet: RJ45 x 2, Auto MDI-X, daisy chain compatible, up to 1000 Mbps
■ USB: USB 2.0 Type-B x 1
■ Operation Interface: 8 buttons, 6 LEDs (plus 4 network LEDs)
■ Case: UL94 V-0 flame retardant, DIN rail/wall mountable
■ Dimensions: 86 x 105 x 49 mm
■ Weight: Approx. 148 g
■ Operating Temperature: -10°C to 70°C | Storage: -20°C to 85°C
■ Humidity: 5% to 80% (non-condensing)
■ Protection Class: IP20
