I-O DATA / DA-4HD/4K

This product is a splitter that can simultaneously output the same video from one 4K-compatible output video device such as a computer to four 4K-compatible display devices such as displays.

■4K compatible HDMI distributor (4 ports)
■Compatible models
Input: Video output device equipped with an HDMI output terminal (computer, game console, etc.)
Output: Video display device equipped with an HDMI input terminal (LCD display, TV, projector, etc.)
*Operation is not guaranteed on all devices.
*To display 4K images, devices that support 4K are required on both the input and output sides.
■Color: Black
■Input terminal: HDMIx1
■Output terminal: HDMIx4
■HDCP: HDCP2.2/1.4
■HDR: Supported
*Subject to specifications and settings of HDMI input device/HDMI output device
*Used in B (fixed mode)
■CEC: Compatible
*CEC function is only valid for ""HDMI input device connected to INPUT"" and ""HDMI output device connected to OUTPUT-1""
*In the case of a cascade connection, the CEC function is only valid between the ""HDMI input device connected to INPUT"" and the ""HDMI output device connected to OUTPUT-1 of the second product connected to OUTPUT-1 of the first product"".
■I/O format
picture:
According to the specifications and settings of the HDMI input device/HDMI output device
*Some video and audio may not be available depending on the combination of devices.
audio:
According to the specifications and settings of the HDMI input device/HDMI output device
*Excluding 5.1ch/7.1ch and HD audio (Dolby AtmosR, Dolby TrueHD, DTS:X?, DTS-HD, etc.)
■Switching method
Main body switch: Manual switching (right side: power supply, left side: mode switching)
*After switching modes, turn off the power and then turn it on again.
■Supported resolution:
3840x2160 @60Hz
1920x1080 @60Hz
*For cases other than the above, please set this product to B (fixed mode) and connect a display that supports the lowest resolution and refresh rate to OUTPUT-1.
Also, depending on the connected display and connection environment, unintended display may occur.
■Maximum resolution: 3840x2160 @60Hz
■Pixel clock: 600MHz
■Power supply voltage rating: AC100V 50/60Hz
■Power consumption: 2.7W (Typ)
■SIZE: Approximately 152(W)x63(H)x20(D)mm *Rubber feet not included
■Body mass: Approx. 110g
■Mass/dimensions when packed: Approx. 330g/Approx. 163(W)x45(D)x177(H)mm
■Operating temperature range: 0 to 40℃
■Using humidity range: 10-90% (no condensation)
■Various acquisition standards:
Compliant with RoHS Directive (10 substances), VCCI Class B, Electrical Appliance and Material Safety Law (AC adapter)
■Recommended HDMI cable:
I-O DATA/DA-PMH/2M, DA-PMH/5M
■Attachments:
AC adapter (PSE compatible product), instruction manual
■Other notes
・HDMI cable is not included with this product. Please prepare separately.
-Active type HDMI cables are not guaranteed to work.
Please use a passive type HDMI cable with a length of 5m or less.
- When displaying 4K video, we recommend using a Premium HDMI cable.
-This product's HDMI does not support ARC.
-The HDMI of this product is not compatible with HEC.
-This product does not support variable refresh rate technologies such as AMD FreeSync and NVIDIA G-SYNC.
■Warranty period: This product only comes with a 1-year manufacturer's warranty.
