SWIT / LA-R480

A standard DMX512 light console that can be operated from zero base. There are 24 channel faders and an A/B page switch, allowing you to control a total of 48 channels.

■48ch DMX512 light console
■Channel: 48
■Submaster: 6
■Master: 1
■DMX: 3-pin XLR female x1, male x1
■Serial connection: up to 4 units (maximum 192ch)
■Power supply:
PowerCON (AC 88-256V 50/60Hz)
■Input x 1, LOOP x 1
■Dimensions: 482 x 265 x 75mm
■Weight: 2.65kg
