Angelbird / AVP1TBCF

A professional CFast 2.0 card developed for audio and video production. Highly compatible with many professional equipment including Atomos, Canon, and Blackmagic Design.

■CFast 2.0 card
■Capacity: 1TB

[General]
■Form factor: CFast
■Size: 42.8 x 36.4 x 3.3 mm
■Weight: 10.0g

【performance】
■Continuous read speed: up to 560MB/s
■Continuous writing speed: up to 498MB/s

[Reliability]
■MTBF (Mean Time Between Failures): 2,000,000 hours or more
■Data reliability: Built-in EDC, ECC function
■Data retention: 10 years at 25°C
■Certification: RoHS, CE, FCC

[Power specifications]
■DC input: 3.3V ± 5%
■Power consumption (idle/maximum): 0.37W/2.22W

[Technical specifications]
■Interface: CFast 2.0 compliant
■Overprovisioning: ~7.6%
■Features: Temperature sensor, TRIM, ECC error correction, EMS protection, built-in cache, SMART

[Usage environment]
■Shock resistance: 50G
■Vibration: 3.1G
■Operating temperature: 0~+70°C
■Storage temperature: -40~85°C
■Operating humidity: 5-95% (no condensation)

[Compatible devices]
■Compatible products:
Atomos products, Blackmagic Design products, Phantom products, Canon products, Hasselblad products, etc.

[Included items]
■Contents:
AV PRO CF, warranty activation code, additional software licenses and content

*Does not work with ARRI AMIRA and ARRI ALEXA Mini. An ARRI-specific CFast 2.0 card (model name: AV PRO AR 256) is available for these cameras.
ARRI model number: #K2.0021432 (1 piece)/#K0.0021433 (3 pieces)
Please contact your ARRI dealer for more information about the card.
*For Canon EOS C200 and EOS C300 Mark II, we recommend using a card with a capacity of 256GB.
