Electro-Voice / EVID-S10.1DW

Electro-Voice's EVID-S10.1D subwoofer is a compact, high-performance dual 10-inch (254 mm) woofer speaker. It provides superior performance for professional and commercial audio applications. Designed and engineered for background/foreground music and audio reinforcement applications, ideal for indoor and outdoor applications such as restaurants, bars, retail stores, health clubs, hospitals, theme parks, and leisure facilities.

Frequency response (-10 dB)1: 33 Hz to 500 Hz
Output sound pressure level 2: 94 dB
Maximum sound pressure level SPL (calculated value): 120 dB (126 dB peak)
Allowable input: 400 W (1600 W peak) continuous pink noise (100 hours)
Low impedance: Yes
Nominal impedance: (2) 8 ? (stereo mode), (1) 4 ? (mono mode)
Recommended highpass: 40 Hz (24 dB/octave)
Input transformer (70 V/100 V): Optional accessories
Transformer tap: Optional accessory
LF transducer: 2 x 10 inches (254 mm)
Input Connectors: 2 x 4-pin connectors (Euroblock) with removable locks - input and output. Maximum wire size 12 AWG (2.05 mm).
Environmental specifications: IP-54 (IEC-60529 compliant), IP-65 (with port cover installed)
Color: white
Dimensions (height x width x depth) 3: 356 mm x 651 mm x 491 mm
Body weight 3: 17.9 kg
Packing weight: 21 kg
Attached hardware: (2) subwoofer legs, hex wrench, weatherproof input cover, (8) weatherproof input cover screws, (2) IP65 port cover, (12) IP65 port cover screws
Packing quantity: 1
