・ 4-track recording + bound track, with unlimited track additions possible
・ Dual AD circuit + 32-bit float audio technology, allowing clipping-free recording without gain adjustment
- 2 XLR/phone input jacks (with phantom power) for connecting microphones, guitars, keyboards and other instruments
- 4 faders for controlling the volume of each track
- Built-in microphone for recording musical ideas anytime, anywhere
- Color LCD for easy UI navigation
・ EFFECT section with EQ, reverb, delay, and guitar effects
・ RHYTHM section with drum patterns
・ USB audio interface function with 32-bit float audio support
・ Operates on 4 AA batteries or AC power (optional)

Number of input/output channels
Input
Built-in microphone (mono): 1
XLR/TS input (mono): 2
Output
Headphones: 1

Input
XLR/TS input
Connector: XLR/TS combo jack x 2 (balanced, XLR: pin two hot)
Input gain: No adjustment required (dual AD converter circuit employed)
　Input impedance:
XLR: 2.3 kΩ
TS: 1 MΩ
Maximum input level:
XLR: +4 dBu
TS: +10 dBu
Phantom power: +48 V (switchable for each input A and B)
Equivalent input noise:
XLR: -120 dBu or less (IHF-A)
　　TS: -107 dBu or less (IHF-A)
Frequency Response
XLR: -0.5 /+0.0 dB: 20 Hz to 20 kHz
TS: -0.2 /+0.0 dB: 20 Hz to 20 kHz
Built-in Microphone Input
Directivity: Omnidirectional
　　Input gain: No adjustment required (dual AD converter circuit employed)
Maximum input sound pressure: 115 dB SPL

■ Output
Headphones:
Connector: 3.5 mm stereo mini jack x 1
Output impedance: 10 Ω
Maximum output level: 20 mW + 20 mW (into 32 Ω load)

■ Recorder
　Maximum simultaneous recording tracks: 2
Recording format: WAV 48 kHz, 32-bit float, mono
Recording media:
microSDHC-compliant cards 4 GB to 32 GB
microSDXC-compliant cards 64 GB to 1 TB

Display
2-inch full-color LCD (240 x 320 dots)

■USB
connector: USB Type-C
* Please use a USB cable that supports data transfer. USB bus power operation supported.
Audio interface functions:
Class: USB 2.0 High Speed
Sampling frequency: 48 kHz
Bit rate: 24-bit/32-bit float
Channel input/output: 2 in/2 out
Mass storage function: USB 2.0 High Speed

■ Power source
Dry cell batteries: 4 AA batteries (alkaline, nickel-metal hydride, lithium)
AC adapter: ZOOM AD-17 (5 V/1.0A)
*USB bus power operation supported

■ Approximate battery life during continuous use
Alkaline batteries: approx. 7 hours
Nickel-metal hydride battery (1900 mAh): approx. 6 hours
Lithium battery: approx. 14 hours
* Conditions of use: 1-track recording, 1-track playback, phantom power OFF, headphones 32 Ω load, Power Saving ON
* The above figures are only a guide. * Battery life is based on our testing methods. It will vary greatly depending on the conditions of use.

Power consumption: 5 W
External dimensions: 74 mm (W) x 138 mm (D) x 36 mm (H)
Weight (including batteries): 287 g
