SCHOEPS / MiniCMIT

Equipped with a 4th-order low-cut filter fixed at 70Hz, this is a small shotgun microphone that reproduces the characteristics of the CMIT 5 in a more compact form.

[直輸入品][Direct Import]

■Main features
・Directivity: Super unidirectional (supercardioid)
・Frequency band: 60Hz to 20kHz
・Sensitivity: -35 dB (V/Pa), 17 mV/Pa
・Equivalent noise level (A-weighted): 14dB
・Equivalent noise level (CCIR): 24dB
・SN ratio (A-weighted): 80dB
・Maximum sound pressure level (THD < 0.5 %): 130 dB-SPL (P48)/115 dB-SPL (P12)
・Maximum output voltage: 1 V (0 dBV) at 2 kΩ load
・Low cut filter: Fixed, 70 Hz, 24 dB/oct.
・Recommended minimum load impedance: 2 kΩ
・Output impedance: 100Ω
・Maximum cable length: >100 m
・SCHOEPS RFI shield: Yes
・Power supply standard/effective range:
　P48 / >24V
　P12 / >11V
・Current consumption: 2.3 mA (P48)
・Common mode rejection ratio (at 1 kHz): >55 dB or more
・Output: XLR-3M, analog, 1 channel
・Length: 151mm
・Mic diameter: 21mm
・Weight: 78g
