GREEN HOUSE / GH-LCT22D-BK

This 21.45” wide touch panel LCD monitor supports 10-point multi-touch.

■21.45“ wide touch panel LCD monitor

[LCD body]
■Panel type: 21.45” VA panel (non-glare)*1
■Maximum display area: 478.66(W)x260.28(H)mm
■Maximum display resolution: 1920x1080 (Full HD)
■Pixel pitch: 0.2493(H)x 0.241(V)mm
■Maximum display color: Equivalent to 16.77 million colors (Full Color)
■Standard viewing angle: 178° up/down, 178° left/right
■Contrast ratio:
3000:1 (50,000,000:1 with DCR function on)
■Brightness: 250cd/m?
■Response time:
16ms (with Over Drive function on: 14 ms(GTG))
■Horizontal frequency: 30kHz to 85kHz
■Vertical frequency: 48Hz to 75Hz
■HDCP support: YES
■Video input terminal:
Analog RGB (mini D-Sub15) terminal x1
DisplayPort terminal (Ver.1.2) x1 (HDCP supported)
HDMI terminal x1 (HDCP Supported)
■Audio input/output terminal:
Audio input: Stereo mini jack (3.5mm) x1
Audio output: Stereo mini jack (3.5mm) x1
■Power management:
VESA DPM compatible
■Plug & Play function:
VESA DDC2B
■Screen control: OSD
■Speakers:
Stereo speaker (2.5Wx2.5W) on-board
■Power Consumption:
Maximum 43W (in power saving mode: less than 0.5W)
Standard Mode: 13.65W (ENERGY STAR standard)
■Power Supply: AC100V 50/60Hz
■Weight: Approx. 3.9kg
■Dimensions: Approx. 520(W)x313(H)x82(D)mm
■Operating Temperature range: 0°C to 40°C
■Operating humidity range: 10% to 85% (non-condensing)
■Storage temperature range: -20°C to 55°C
■Storage humidity range: 10% to 90% (non-condensing)
■Tilt angle up: 15 to 50°
■VESA mount interface: 100mm (0.7mm pitch)M4.0,L10 mm
■Flicker-free: Supported
■Anti-theft hole: 3x7mm supported

[Touch Panel Specification]
■Panel: Glass*1
■Transmittance: 85% or more
■Thickness: Approx. 1.8mm
■Hardness: 6H
■Touch method: Capacitance method (10-point multi-touch supported)
■Transmission method: USB1.1(Full Speed)

[USB hub function]
■Number of ports (downstream)
Side port: 1
Rear port: 2
■Data transfer rate:
Side port: Max. 5Gbps (theoretical value)
Rear port: Max. 480Mbps (theoretical value)
■Interface:
Side port: USB3.1 Gen1(Type-A)
Rear port: USB2.0 (Type-A)
■Power Supply Method:
Self-powered * Supplied from display power supply
■Power Supply:
Side Port: Within 900mA
Rear Port: Within 500mA each
*Power consumption in standard mode is measured according to ENERGY STAR test standard
*1 Because a protective glass filter is installed, 1 Due to the protective glass filter, reflection may occur.
■Accessories:
Dedicated power cable (1.5m), HDMI cable (1.5m), DisplayPort cable (1.5m),
USB Type-A to Type-B cable (1.5m), Instruction manual and warranty card
■Compatible models:
Windows PC, Apple Mac series
